Harley-Davidson Harley Davidson XL 1200C Sportster Custom (2013) technical specifications

Harley-Davidson Harley Davidson XL 1200C Sportster Custom technical specifications

Harley-Davidson Harley Davidson XL 1200C Sportster Custom is produced in 2013. Engine is Four stroke, 45° V-Twin, OHV, 2 valves per cylinder., displacement 1199 cc / 73.2 cub in. Harley-Davidson Harley Davidson XL 1200C Sportster Custom wet weight is 264 kg / 582 lbs. Harley-Davidson Harley Davidson XL 1200C Sportster Custom has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson XL 1200C Sportster Custom
Years: 2013
Engine: Four stroke, 45° V-Twin, OHV, 2 valves per cylinder.
Capacity: 1199 cc / 73.2 cub in.
Bore x Stroke: 88.8 x 96.8 mm
Cooling System: Air cooled,
Compression Ratio: 9.7:1
Induction: Electronic Sequential Port Fuel Injection (ESPFI)
Ignition: Digital CDI
Starting: Electric
Max Torque: 79 ft/lbs./ 107 Nm @ 3500 rpm
Transmission: 5 Speed
Final Drive: Belt
Gear Ratio: 1st 9.315 2nd 6.653 3rd 4.948 4th 4.102 5th 3.517
Frame: Mild steel, tubular frame; circular sections; cast junctions Swingarm Mild steel, rectangular tube sections, stamped junctions; MIG welded
Front Suspension: 39mm Fork,
Front Wheel Travel: 144 mm / 5.6 in
Rear Suspension: Coil-over; preload dual-adjustable,
Rear Wheel Travel: 54 mm / 2.1 in
Front Brakes: Single 300mm discs 2 38mm piston caliper
Rear Brakes: Single 300mm discs 2 38mm piston caliper
Front Wheel: Chrome, 5-Spoke Cast Aluminum
Rear Wheel: Chrome, 5-Spoke Cast Aluminum
Front Tyre: D402F MH90-21 54H
Rear Tyre: D401 150/80B16 71H
Rake: 30°
Trail: 107 mm / 4.2 in
Dimensions: Length 2225 mm / 87.6 in
Wheelbase: 1520 / 59.8 in
Seat Height: Laden2 26.6 in / 675.64 mm Unladen 28.5 in / 723.9 mm
Ground Clearance: 110 mm / 4.3 in
Wet Weight: 264 kg / 582 lbs
Oil Capacity (w/filter): 2.6 Litres
Fuel Capacity: 17 Litres / 4.5 US gal
