Harley-Davidson Harley Davidson XG 750 Street (2016-17) technical specifications

Harley-Davidson Harley Davidson XG 750 Street technical specifications

Harley-Davidson Harley Davidson XG 750 Street is produced in 2016-17. Engine is Four stroke, Revolution X™ 60° V-Twin, SOHC, 4 valves per cylinder., displacement 749 cc / 46 cub in. Harley-Davidson Harley Davidson XG 750 Street weighs 222 kg / 489 lbs. Harley-Davidson Harley Davidson XG 750 Street has 7 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson XG 750 Street
Years: 2016-17
Engine: Four stroke, Revolution X™ 60° V-Twin, SOHC, 4 valves per cylinder.
Capacity: 749 cc / 46 cub in.
Bore x Stroke: 85 x 66 mm
Cooling System: Liquid cooled
Compression Ratio: 11.0:1
Oil Capacity: 3.1 Litres / 3.3 US qt.
Induction: Mikuni Single Port Fuel Injection, 38 mm bore
Ignition: Electronic
Starting: Electric
Max Torque: 59 Nm / 6.0 kgf-m / 43.5 ft/lb @ 4000 rpm
Clutch: Multi-plate with diaphragm spring in oil bath
Transmission: 6 Speed
Final Drive: Belt
Gear Ratio: 1st 14.25 / 2nd 10.07 / 3rd 7.45 / 4th 5.99 / 5th 5.04 / 6th 4.53:1
Frame: Mild tubular steel w/ rectangular backbone
Front Suspension: Non-adjustable 37mm forks
Front Wheel Travel: 140 mm / / 5.5 in
Rear Suspension: Spring-preload adjustable dual shocks
Rear Wheel Travel: 94 mm / 3.5 in
Front Brakes: Single disc, 2 piston caliper
Rear Brakes: Single disc, 2 piston caliper
Front Wheel: Black, 7-Spoke Cast Aluminum with Machined Rim Highlights
Rear Wheel: Black, 7-Spoke Cast Aluminum with Machined Rim Highlights
Front Tyre: 100/80 R17
Rear Tyre: 140/75 R15
Rake: 32°
Trail: 110 mm / 4.5 in.
Dimension: Length 2225 mm / 87.6 in.
Wheelbase: 1534 mm / 60.4 in.
Seat Height: Laden 654 mm / 25.7 in. Unladen 709 mm / 27.9 in.
Ground Clearance: 145 mm / 5.7 in.
Dry Weight: 222 kg / 489 lbs
Fuel Capacity: 13.1 Litres / 3.5 US gal
