Harley-Davidson Harley Davidson Pan America 1250 Special (2021) technical specifications

Harley-Davidson Harley Davidson Pan America 1250 Special technical specifications

Harley-Davidson Harley Davidson Pan America 1250 Special is produced in 2021. Engine is Four stroke, 60° V-twin Revolution Max 1250, Chain-driven, DOHC, hydraulic self-adjusting lifters, intake & exhaust VVT, four valves per cylinder, displacement 1252 cc / 76.3 cu-in , produces power 150 hp / 112 kW @ 9000 rpm and 127 Nm / 94 lb-ft @ 6750 rpm. Harley-Davidson Harley Davidson Pan America 1250 Special weighs 239 kg / 527 lbs. Harley-Davidson Harley Davidson Pan America 1250 Special has 8 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson Pan America 1250 Special
Years: 2021
Engine: Four stroke, 60° V-twin Revolution Max 1250, Chain-driven, DOHC, hydraulic self-adjusting lifters, intake & exhaust VVT, four valves per cylinder
Capacity: 1252 cc / 76.3 cu-in
Bore x Stroke: 105 x 72 mm
Compression Ratio: 13.0:1
Cooling System: Liquid cooled
Exhaust: 2-into-1-into-1, catalyst in header
Lubrication: Pressurized Wet Sump
Induction: Electronic Sequential Port Fuel Injection (ESPFI)
Starting: Electric
Max Power: 150 hp / 112 kW @ 9000 rpm
Max Torque: 127 Nm / 94 lb-ft @ 6750 rpm
Clutch: Mechanical, 8 plate wet, assist & slip, 1090N
Transmission: 6 Speed
Final Drive: Chain, 19/48 ratio
Primary Drive: Gear, 49/89 ratio
Gear Ratios: 1st 13.11 / 2nd 9.687 / 3rd 7.509 / 4th 6.057 / 5th 5.08 / 6th 4.436
Frame: Stressed-member, high strength low alloy steel trellis frame; stamped, cast, and forged junctions; MIG welded; aluminum forged mid-structure
Swingarm: One-piece cast aluminum
Front Suspension: 47mm inverted fork with electronically adjustable semi-active damping control (optional: Adjustable Right Height (ARH)), Aluminum fork triple clamps
Front Wheel Travel: 191 mm / 7.5 in
Rear Suspension: Linkage-mounted monoshock with automatic electronic preload control and semi-active compression & rebound damping (optional: adjustable Ride Height (ARH))
Rear Wheel Travel: 191 mm / 7.5 in
Front Brakes: 2x 320mm discs, radially mounted, monoblock, 4-piston caliper
Rear Brakes: Single 280mm disc, floating, single piston caliper
ABS System: Standard
Wheels: Aluminum cast, satin black (optional: annodized aluminum tubeless laced)
Front Rim: 3.0 x 19
Rear Rim: 4.50 x 17
Front Tyre: 120/70R19 60V
Rear Tyre: 170/60R17 72V
Rake: 25°
Trail: 157 mm / 6.2 in
Dimensions: Length: 2265 mm / 89.2 in Width: 965 mm / 38 in Height: 1510 mm / 59.4 in
Wheelbase: 1580 mm / 62.2 in
Seat Height Laden: 789 mm / 31.1 in - 772 mm / 30.4 in (with optional suspension)
Seat Height Unladen: 850 mm / 33.4 in - 830 mm / 32.7 in (with optional suspension)
Ground Clearance: 210 mm / 8.3 in
Dry Weight: 239 kg / 527 lbs
Wet Weight: 254 kg / 559 lbs
Fuel Capacity: 21.2 Litres / 5.6 US gal
