Harley-Davidson Harley Davidson Hydra-Glide Revival (2024) technical specifications

Harley-Davidson Harley Davidson Hydra-Glide Revival is produced in 2024. Engine is Four stroke, V-Twin, Milwaukee-Eight 114, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder, displacement 1868 cc / 114 cu in Harley-Davidson Harley Davidson Hydra-Glide Revival weighs 322.5 kg / 711 lbs. Harley-Davidson Harley Davidson Hydra-Glide Revival has 8 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Harley Davidson Hydra-Glide Revival
Years:	2024
Produciton:	1750 units
Engine:	Four stroke, V-Twin, Milwaukee-Eight 114, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Capacity:	1868 cc / 114 cu in
Bore x Stroke:	102 x 114 mm
Cooling System:	Air cooled
Compression Ratio:	10.5:1
Exhaust:	Chrome, 2-into-2 shorty dual; catalist in muffler
Induction:	Electronic Sequential Port Fuel Injection (ESPFI)
Lubrication:	Pressurized, dry-sump with oil cooler
Ignition:	Single-fire, non-wasted, map-controlled spark ignition
Starting:	Electric
Max Torque:	161 Nm / 119 lb-ft @ 3000 rpm
Clutch:	Multi-plate, wet
Transmission:	6 Speed
Primary Drive:	Chain, 34/46 ratio
Final Drive:	Belt
Gear Ratio:	1st 9.311 2nd 6.454 3rd 4.793 4th 3.882 5th 3.307 6th 2.79
Lean Angle Right:	27.4?
Lean Angle Left:	27.4?
Front Suspension:	Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; "beer can" covers
Travel Front:	130 mm / 5.1 in
Rear Suspension:	Hidden, free piston, coil-over monoshock; 43mm stroke; cam-style preload adjustment
Rear Travel:	86.4 mm / 3.4 in
Front Brakes:	2 x 300mm discs, 4 piston fixed
Rear Brakes:	Single 292mm disc, 2 piston floating
ABS:	Standard
Wheels Front:	Chrome, steel laced
Wheels Rear:	Chrome, steel laced
Front Tyre:	BW 130/90B16 73H
Rear Tyre:	BW 150/80B16 77H
Rake:	30?
Trail:	145 mm / 5.7 in
Dimensions:	Length 2415 mm / 95.1 in
Wheelbase:	1631 mm / 64.2 in
Seat Height:	Laden 663 mm / 26.1 in
Ground Clearance:	119 mm / 4.7 in
Dry Weight:	322.5 kg / 711 lbs
Wet Weight:	336.6 kg / 742 lb
Fuel Capacity:	18.9 Litres / 5 US gal
