Harley-Davidson Harley Davidson FXSTD Softail Deuce (2007) technical specifications
Harley-Davidson Harley Davidson FXSTD Softail Deuce is produced in 2007. Engine is Four stroke, 45° V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder, displacement 1584 cc / 96 cu-in Harley-Davidson Harley Davidson FXSTD Softail Deuce weighs 301 kg / 663 lbs. Harley-Davidson Harley Davidson FXSTD Softail Deuce has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson FXSTD Softail Deuce |
| Years: | 2007 |
| Engine: | Four stroke, 45° V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder |
| Capacity: | 1584 cc / 96 cu-in |
| Bore x Stroke: | 95.3 x 111.1 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.2:1 |
| Induction: | Electronic Sequential Port Fuel Injection (ESPFI) |
| Ignition: | Single-fire, non-wasted, map-controlled spark ignition |
| Starting: | Electric |
| Max Torque: | 124.7 Nm / 92 ft/ lbs. @ 3000 rpm |
| Clutch: | Multi-plate, wet |
| Transmission: | 6 Speed |
| Final Drive: | Belt |
| Frame: | Mild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded |
| Front Suspension: | 41.3 mm telescopic, “beer can” covers |
| Rear Suspension: | Hidden, horizontal-mounted, coil-over shock |
| Front Brakes: | Single 292mm disc 4 piston caliper |
| Rear Brakes: | Single 292mm disc 4 piston caliper |
| Front Tyre: | MH90-21 54H |
| Rear Tyre: | 160/70B17 73V |
| Rake: | 32° |
| Fork Angle: | 33.5° |
| Trail: | 127 mm / 5.0 in |
| Dimensions: | Length 2423.2 mm / 95.4 in Width 913.0 mm / 35.9 in Height 1168.0 mm / 46.0 in |
| Wheelbase: | 1691.6 mm / 66.6 in |
| Seat Height: | Laden2 635.0 mm / 25.0 in Unladen 681.7 mm / 26.8 in |
| Ground Clearance: | 122 mm / 4.8 in |
| Dry Weight: | 301 kg / 663 lbs |
| Wet Weight: | 309 kg / 682 lbs |
| Fuel Capacity: | 18 5 Litres / 4.9 US gal |
