Technical specifications
|
| Model: |
Harley Davidson FXSB-SE Pro Street Breakout CVO |
| Years: |
2017 |
|
Engine:
|
Screamin' Eagle Twin Cam 110B
|
|
Capacity:
|
1801 cc / 110.0 cu in
|
|
Bore x Stroke:
|
101.6 x 111.1 mm
|
|
Compression Ratio:
|
9.2:1
|
|
Cooling System:
|
Air cooled
|
|
Exhaust:
|
Blacked-out staggered blunt cut mufflers
|
|
Induction:
|
Electronic Sequential Port Fuel Injection (ESPFI)
|
|
Starting:
|
Electric
|
|
Max torque:
|
151 Nm / 15.4 kgf-m / 111.4 ft-lb @3500 rpm
|
|
Transmission:
|
6 Speed
|
|
Primary Drive:
|
Chain, 34:46 ratio
|
|
Gear Ratios:
|
1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.790:1
|
|
Final Drive:
|
Belt
|
|
Front Brakes:
|
Dual discs, 4-piston fixed caliper
|
|
Rear Brakes:
|
Single disc, 2-piston floating caliper
|
|
Wheels:
|
Scorched chrome, Aggressor custom wheel
|
|
Front Tyre:
|
130/60B19 61H
|
|
Rear Tyre:
|
240/40R18 79V
|
|
Lean Angle (Left):
|
25.5º
|
|
Lean Angle (Right):
|
24.8º
|
|
Rake:
|
35º
|
|
Trail:
|
196 mm / 7.7 in
|
|
Dimensions:
|
Length: 2330 mm / 91.7 in
|
|
Wheelbase:
|
1680 mm / 66.1 in
|
|
Ground Clearance:
|
120 mm / 4.7 in
|
|
Seat Height:
|
660 mm / 26.0 in
|
|
Dry Weight:
|
318 kg / 701 lbs
|
|
Wet Weight:
|
332 kg / 732 lbs
|
|
Fuel Capacity:
|
18.9 Litres / 5.0 US gal
|
|
Oil Capacity (with filter):
|
3.3 L / 3.5 US qts
|
