Harley-Davidson Harley Davidson FXE-F 1340 Fat Bob (1980-85) technical specifications

Harley-Davidson Harley Davidson FXE-F 1340 Fat Bob technical specifications

Harley-Davidson Harley Davidson FXE-F 1340 Fat Bob is produced in 1980-85. Engine is Four stroke, 45° V-Twin, OHV, 2 valves per cylinder., displacement 1337 cc / 81.5 cu-in , produces power 67 hp / 48.9 kW @ 5800 rpm and 90.8 Nm / 67 lb.-ft. @ 3600 rpm. Harley-Davidson Harley Davidson FXE-F 1340 Fat Bob top speed is 105 mph. Harley-Davidson Harley Davidson FXE-F 1340 Fat Bob weighs 256 kg / 564.3 lbs. Harley-Davidson Harley Davidson FXE-F 1340 Fat Bob has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson FXE-F 1340 Fat Bob
Years: 1980-85
Engine: Four stroke, 45° V-Twin, OHV, 2 valves per cylinder.
Capacity: 1337 cc / 81.5 cu-in
Bore x Stroke: 88.8 x 108.0 mm
Cooling System: Air cooled
Compression Ratio: 7.4:1
Induction: 38mm Keihin carburetor
Ignition: Electronic
Starting: Electric
Max Power: 67 hp / 48.9 kW @ 5800 rpm
Max Torque: 90.8 Nm / 67 lb.-ft. @ 3600 rpm
Transmission: 4 Speed
Final Drive: Chain
Front Suspension: Telehydraulic forks
Rear Suspension: Dual shocks swinging arm fork
Front Brakes: Single disc / 2x 254mm discs optional
Rear Brakes: Single disc
Front Tyre: MT90-16
Rear Tyre: MT90-16
Dry Weight: 256 kg / 564.3 lbs
Fuel Capacity: 15.5 Litres / 4.0 US gal
Consumption Average: 49 mpg
Standing ¼ Mile: 15.0 sec / 89.4 mph
Top Speed: 105 mph
