Harley-Davidson Harley Davidson FLTRU SE Road Glide Ultra CVO (2009) technical specifications
Harley-Davidson Harley Davidson FLTRU SE Road Glide Ultra CVO is produced in 2009. Engine is Four stroke, Twin Cam 110™ Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder, displacement 1804 cc / 110.1 cub in. Harley-Davidson Harley Davidson FLTRU SE Road Glide Ultra CVO wet weight is 427.7 kg / 943 lbs. Harley-Davidson Harley Davidson FLTRU SE Road Glide Ultra CVO has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson FLTRU SE Road Glide Ultra CVO |
| Years: | 2009 |
| Engine: | Four stroke, Twin Cam 110™ Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder |
| Capacity: | 1804 cc / 110.1 cub in. |
| Bore x Stroke: | 101.6 x 111.3 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.15:1 |
| Induction: | Electronic Sequential Port Fuel Injection (ESPFI) |
| Ignition: | Single-fire, non-wasted, map-controlled spark ignition |
| Starting: | Electric |
| Max Torque: | 156 Nm / 15.9 kgf-m / 115 ft/lbs / @ 3750 rpm |
| Clutch: | Hydraulically actuated, 9-plate, wet, with high performance spring |
| Transmission: | 6 Speed |
| Final Drive: | Belt |
| Gear Ratio: | 1st 9.593 / 2nd 6.65 / 3rd 4.938 / 4th 4 / 5th 3.407 / 6th 2.875:1 |
| Frame: | Mild steel, square-section backbone with twin downtubes |
| Front Suspension: | 41.3 mm telescopic, cartridge-style damping |
| Rear Suspension: | Short, air-adjustable shock |
| Front Brakes: | 2 x 292 mm disc, 4 piston caliper |
| Rear Brakes: | Single 292 mm disc, 4 piston caliper |
| Front Tyre: | D408 130/70B18 63H |
| Rear Tyre: | D407 180/55B18 80H |
| Rake: | 26° |
| Trail: | 170 mm / 6.7 in |
| Dimensions: | Length 2595 mm / 102.2 in. |
| Wheelbase: | 1630 mm / 64 in. |
| Seat Height: | Laden 693 mm / 28.4 in Unladen 739 mm / 29.7 in. |
| Ground Clearance: | 120 mm / 4.7 in |
| Gross Vehicle Weight Rating: | 616.9 kg / 1360 lbs |
| Wet Weight: | 427.7 kg / 943 lbs |
| Fuel Capacity: | 22.7 Litres / 6.0 gal |
