Harley-Davidson Harley Davidson FLHX Street Glide (2012) technical specifications

Harley-Davidson Harley Davidson FLHX Street Glide is produced in 2012. Engine is Four stroke, V-Twin, Twin Cam 103™ with Integrated Oil-Cooler, displacement 1690 mm / 103 cu. in Harley-Davidson Harley Davidson FLHX Street Glide wet weight is 373 kg / 822 lbs. Harley-Davidson Harley Davidson FLHX Street Glide has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Harley Davidson FLHX Street Glide
Years:	2012
Engine:	Four stroke, V-Twin, Twin Cam 103™ with Integrated Oil-Cooler
Capacity:	1690 mm / 103 cu. in
Bore x Stroke:	98.4 x 111.3 mm
Cooling System:	Air cooled
Compression Ratio:	9.6:1
Exhaust:	Chrome, 2-1-2 dual exhaust with tapered mufflers
Induction:	Electronic Sequential Port Fuel Injection (ESPFI)
Ignition:	Single-fire, non-wasted, map-controlled spark ignition
Starting:	Electric
Max Torque:	134 Nm / 98.8 ft/lbs @ 3500 rpm
Transmission:	6 Speed
Final Drive:	Belt
Primary Drive:	Chain, 34/46 ratio
Gear Ratio:	1st 9.312 2nd 6.421 3rd 4.774 4th 3.926 5th 3.279 6th 2.790
Frame:	Mild steel, square-section backbone with twin downtubes
Front Suspension:	41.3 mm telescopic, cartridge-style damping, 117mm wheel travel
Rear Suspension:	Short, air-adjustable shock, 51mm wheel travl.
Front Brakes:	2x 292mm disc 4 piston caliper
Rear Brakes:	Single 292mm disc 4 piston caliper
Front Tyre:	D408F BW 130/70B18 63H
Rear Tyre:	D407 BW 180/65B16 81H
Rake:	26°
Trail:	170 mm / 6.7 in
Fork Angle:	29.2°
Dimensions:	Length 2413 mm / 95.0 in. Width 965 mm / 38.0 in. Height 1326 mm / 52.2 in.
Seat Height:	Laden 663 mm / 26.1 in Unladen 688 mm / 27.1 in.
Wheelbase:	1613 mm / 63.5 in
Gross Vehicle Weight Rating:	616.9 kg / 1360 lbs
Wet Weight:	373 kg / 822 lbs
Fuel Capacity:	22.7 Litres / 6.0 gal
