Harley-Davidson Harley Davidson FLHTK Electra Glide Ultra Limited 115th Anniversary (2018) technical specifications

Harley-Davidson Harley Davidson FLHTK Electra Glide Ultra Limited 115th Anniversary technical specifications

Harley-Davidson Harley Davidson FLHTK Electra Glide Ultra Limited 115th Anniversary is produced in 2018. Engine is Four stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder, displacement 1746 cc / 107 cub in Harley-Davidson Harley Davidson FLHTK Electra Glide Ultra Limited 115th Anniversary weighs 398 kg / 877 lbs. Harley-Davidson Harley Davidson FLHTK Electra Glide Ultra Limited 115th Anniversary has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson FLHTK Electra Glide Ultra Limited 115th Anniversary
Years: 2018
Engine: Four stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Capacity: 1746 cc / 107 cub in
Bore x Stroke: 100 x 111 mm
Cooling System: Air cooled
Compression Ratio: 10.0:1
Exhaust: Chrome, 2-1-2 dual exhaust with tapered mufflers
Induction: Electronic Sequential Port Fuel Injection (ESPFI)
Lubrication: Pressurized, dry-sump with oil cooler
Ignition: Single-fire, non-wasted, map-controlled spark ignition
Starting: Electric
Max Torque: 154 Nm / 113.6 lb-ft @ 3250 rpm
Clutch: Multi-plate, wet
Transmission: 6 Speed
Primary Drive: Chain, 34/46 ratio
Final Drive: Belt
Gear Ratio: 1st 9.593 2nd 6.65 3rd 4.938 4th 4.0 5th 3.407 6th 2.875
Frame: Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded
Front Suspension: 41.3 mm telescopic, cartridge-style damping
Rear Suspension: Swingarm Mild steel, two-piece drawn and welded section, forged junctions, MIG welded, Rear Shocks Air-adjustable
Front Brakes: 2 x 300mm discs, 4 piston caliper ABS
Rear Brakes: Single 300 mm disc, 4 piston caliper ABS
Wheels Front: Contrast Chrome Impeller Cast Aluminum
Wheels Rear: Contrast Chrome Impeller Cast Aluminum
Front Tyre: 130/80B17 65H
Rear Tyre: 180/65B16 81H
Rake: 26°
Trail: 170 mm / 6.7 in
Dimensions: Length 2600 mm / 101.8 in
Wheelbase: 1625 mm / 64 in
Seat Height: Unladen 740 mm / 29.1 in Laden 698 mm / 27.5 in
Ground Clearance: 116.8 mm / 4.6 in
Dry Weight: 398 kg / 877 lbs
Wet Weight: 413 kg / 910 lbs
Fuel Capacity: 22.7 Litres / 6 US gal
