Harley-Davidson Harley Davidson FLHTC 1340 Electra Glide Classic (1983-85) technical specifications

Harley-Davidson Harley Davidson FLHTC 1340 Electra Glide Classic technical specifications

Harley-Davidson Harley Davidson FLHTC 1340 Electra Glide Classic is produced in 1983-85. Engine is Four stroke, 45° V-Twin, OHV, 2 valves per cylinder., displacement 1337 cc / 81.5 cu-in , produces power 71 hp / 53.3 kW @ 5000 rpm and 82.5 ft-lb / 111.8 Nm @ 3600 rpm. Harley-Davidson Harley Davidson FLHTC 1340 Electra Glide Classic wet weight is 345.0 kg / 760 lbs. Harley-Davidson Harley Davidson FLHTC 1340 Electra Glide Classic has 1 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson FLHTC 1340 Electra Glide Classic
Years: 1983-85
Engine: Four stroke, 45° V-Twin, OHV, 2 valves per cylinder.
Capacity: 1337 cc / 81.5 cu-in
Bore x Stroke: 88.8 x 108 mm
Cooling System: Air cooled
Compression Ratio: 8.5:1
Induction: 38mm Keihin carburetor
Ignition: Electronic
Starting: Electric
Max Power: 71 hp / 53.3 kW @ 5000 rpm
Max Torque: 82.5 ft-lb / 111.8 Nm @ 3600 rpm
Transmission: 5 Speed
Final Drive: Chain
Frame: Double-downtube, full-cradle frame box-section steel swing arm
Front Suspension: Center-axle fork with 41mm tubes
Frnt Wheel Travel: 117 mm / 4.6 in
Rear Suspension: Dual shock absorbers, adjustable for spring preload
Rear Wheel Travel: 97 mm / 3.8 in
Front Brakes: 2x 292mm discs 4 piston calipers
Rear Brakes: Single 292mm disc 4 piston caliper
Front Tyre: MT 90-16
Rear Tyre: MT 90-16
Wet Weight: 345.0 kg / 760 lbs
Fuel Capacity: 19 Litres / 5.0 US gal
