Ducati Streetfighter V4 S (2020) technical specifications

Ducati Streetfighter V4 S technical specifications

Ducati Streetfighter V4 S is produced in 2020. Engine is Four stroke, Desmosedici Stradale 90° V4, rearward-rotating crankshaft, 4 Desmodromically actuated valves per cylinder, displacement 1103 cc / 67.3 cu in , produces power 208 hp / 153 kW @ 12,750 rpm and 123 Nm / 90.4 lb-ft @ 11,500 rpm. Ducati Streetfighter V4 S weighs 178 kg / 392 lbs. Ducati Streetfighter V4 S has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: Streetfighter V4 S
Years: 2020
Engine: Four stroke, Desmosedici Stradale 90° V4, rearward-rotating crankshaft, 4 Desmodromically actuated valves per cylinder
Capacity: 1103 cc / 67.3 cu in
Bore x Stroke: 81 x 53.5 mm
Compression Ratio: 14.0:1
Cooling System: Liquid cooled
Exhaust: 4-2-1-2 system, with 2 catalytic converters and 2 lambda probes
Emission: Euro 4
Induction: Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies
Starting: Electric
Max Power: 208 hp / 153 kW @ 12,750 rpm
Max Torque: 123 Nm / 90.4 lb-ft @ 11,500 rpm
Clutch: Hydraulically controlled slipper and self-servo wet multiplate clutch
Transmission: 6 speed with Ducati Quick Shift (DQS) up/down EVO 2
Final Drive: Chain, front sprocket 15, rear sprocket 42
Gear Ratios: 1st 38/14 2nd 36/17 3rd 33/19 4th 32/21 5th 30/22 6th 30/24
Primary Drive Ratio: Straight cut gears, Ratio 1.80:1
Frame: Aluminum alloy "Front Frame"
Front Suspension: Öhlins NIX30 43 mm fully adjustable fork with TiN treatment. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode.
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Fully adjustable Ohlins TTX36 unit. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode. Aluminium single-sided swingarm.
Rear Wheel Travel: 130 mm / 5.1 in
Front Brakes: 2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema® (M4.30) 4-piston callipers with Bosch Cornering ABS EVO
Rear Brakes: 245 mm disc, 2-piston calliper with Bosch Cornering ABS EVO
Front Wheel: 3-spokes forged aluminum alloy 3.50" x 17"
Rear Wheel: 3-spokes forged aluminum alloy 6.00" x 17"
Front Tyre: Pirelli Diablo Rosso Corsa 2 120/70 ZR17
Rear Tyre: Pirelli Diablo Rosso Corsa 2 200/60 ZR17
Rake: 24,5°
Trail: 100 mm / 4 in
Wheelbase: 1488 mm / 58.6 in
Seat Height: 845 mm / 33.3 in
Dry Weight: 178 kg / 392 lbs
Wet Weight: 199 kg / 439 lbs
Fuel Capacity: 16 Litres / 4.23 US gal
