Ducati Scrambler Full Throttle (2015-16) technical specifications

Ducati Scrambler Full Throttle technical specifications

Ducati Scrambler Full Throttle is produced in 2015-16. Engine is Four stroke, 90° “L” twin cylinder, SOHC, desmodromic 2 valve per cylinder, displacement 803 cc / 49.0 cub in , produces power 55 kW / 75 hp @ 8250 rpm and 68 Nm / 6.9 kgf-m / 50 lb-ft @ 5750 rpm. Ducati Scrambler Full Throttle weighs 170 kg / 375 lbs. Ducati Scrambler Full Throttle has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: Scrambler Full Throttle
Years: 2015-16
Engine: Four stroke, 90° “L” twin cylinder, SOHC, desmodromic 2 valve per cylinder
Capacity: 803 cc / 49.0 cub in
Bore x Stroke: 88 x 66 mm
Cooling System: Air cooled
Compression Ratio: 11.0:1
Induction: Electronic fuel injection, 50 mm throttle bodies
Ignition: Marelli electronic
Starting: Electric
Exhaust: Exhaust system with twin stainless steel mufflers with aluminium exterior cover, catalytic converter and 2 lambda probes
Max Power: 55 kW / 75 hp @ 8250 rpm
Max Torque: 68 Nm / 6.9 kgf-m / 50 lb-ft @ 5750 rpm
Clutch: APTC wet multiplate with mechanical control
Transmission: 6 Speed
Final Drive: Chain, front spocket 15, rear sprocket 46
Primary Drive: Straight cut gears, ratio 1.85:1
Gear Ratio: 1st 20/13, 2nd 30/18, 3rd 28/21, 4th 26/23, 5th 22/22, 6th 24/26
Frame: Tubular steel Trellis frame
Front Suspension: Upside down Kayaba 41 mm fork
Front Wheel Travel: 150 mm / 5.9 in
Rear Suspension: Kayaba rear shock, pre-load adjustable
Rear Wheel Travel: 150 mm / 5.9 in
Front Brakes: Single 330 mm disc, 4-piston caliper with ABS as standard equipment
Rear Brakes: Single 245 mm disc, 1-piston caliper with ABS as standard equipment
Front Wheel: 10-spoke in light alloy 3.00" x 18"
Rear Wheel: 10-spoke light alloy 5.50" x 17"
Front Tyre: 110/80 R18 Pirelli MT 60 RS
Rear Tyre: 180/55 R17 Pirelli MT 60 RS
Rake: 24°
Trail: 112 mm / 4.4 in
Total steering lock: 35°
Dimensions: Length 2100 - 2165 mm / 82.7 - 85.2 in Height 1150 mm / 45.3 in Width 845 mm / 33.3 in
Wheelbase: 1455 mm / 57.3 in
Seat Height: 790 mm / 31.1 in. low seat 770 mm / 30.3 in. available as accessory
Dry Weight: 170 kg / 375 lbs
Wet Weight: 186 kg / 410 lbs
Fuel Capacity: 13.5 Litres / 3.57 US gal / 3.0 Imp gal
Equipment: Steel tank with interchangeable aluminium side panels, headlight with glass lens, LED light-guide and interchangeable aluminium cover, LED rear light with diffusive lens, LCD instruments with interchangeable aluminium cover, machine-finished aluminium belt covers, 18’’ front, 17’’ rear wheels, underseat storage compartment with USB socket Classic equipment Spoked aluminium wheels, front and rear aluminium mudguards, seat with dedicated design, fuel tank with black stripe, dedicated logo, high plate support. Instrumentation LCD Ducati electronics dual-channel ABS Versions Dual seat
