Ducati Multistrada 950 (2019) technical specifications

Ducati Multistrada 950 technical specifications

Ducati Multistrada 950 is produced in 2019. Engine is Testastretta, L-Twin cylinder, 4 valves per cylinder, Desmodromic, displacement 937 cc / 57.2 cu in , produces power 83.1 kW / 113 hp @ 9000 rpm and 96.2 Nm / 9.8 kgf-m / 71 lb-ft @ 7750 rpm. Ducati Multistrada 950 weighs 204 kg / 450 lbs. Ducati Multistrada 950 has 1 photos.

Technical specifications

+ Add to 'Compare list'
Model: Multistrada 950
Years: 2019
Engine: Testastretta, L-Twin cylinder, 4 valves per cylinder, Desmodromic
Capacity: 937 cc / 57.2 cu in
Bore x Stroke: 94 x 67.5 mm
Compression Ratio: 12.6:1
Cooling System: Liquid cooled
Induction: Electronic fuel injection system, 53 mm throttle bodies with Ride-by-Wire system
Exhaust: Stainless steel single muffler, Catalytic converter and 2 lambda probes
Ignition: Electronic
Starting: Electric
Max Power: 83.1 kW / 113 hp @ 9000 rpm
Max Torque: 96.2 Nm / 9.8 kgf-m / 71 lb-ft @ 7750 rpm
Clutch: Slipper and self-servo wet multiplate clutch with hydraulic control
Transmission: 6-Speed
Primary Drive Ratio: Straight cut gears, ratio 1.84 : 1
Gear Ratios: 1st 37:15 / 2nd 30:17 / 3rd 28:20 / 4th 26:22 / 5th 24:23 / 6th 23:24
Final Drive Ratio: 15:43
Final Drive: Chain, Front sprocket Z15, Rear sprocket Z43
Frame: Tubular steel trellis frame
Front Suspension: 48 mm fully adjustable USD fork
Front Wheel Travel: 170 mm / 6.7 in
Rear Suspension: Fully adjustable monoshock, Remote spring preload adjustment, Aluminium double-sided swingarm
Rear Wheel Travel: 170 mm / 6.7 in
Front Brakes: 2 x 320 mm semi-floating discs, Radially mounted Brembo monobloc 4-piston 2-pad callipers, Radial Master Cylinder, Bosch Cornering ABS
Rear Brakes: Single 265mm disc, 2-piston floating calliper, Bosch Cornering ABS
Front Wheel: Light alloy casted 3.0″ x 19″
Rear Wheel: Light alloy casted 4.5″ x 17″
Front Tyre: 120/70 - ZR19, Pirelli Scorpion Trail II
Rear Tyre: 170/60 - ZR17, Pirelli Scorpion Trail II
Rake: 25°
Trail: 106 mm / 4.2 in
Wheelbase: 1594 mm / 62.8 in
Seat Height: 840 mm / 33.1 in, 860 mm /33.9 in with high seat accessory, 820 mm / 32.3 in with low seat
Dry Weight: 204 kg / 450 lbs
Wet Weight: 227 kg / 500 lbs
Fuel Capacity: 20 Litres / 5.3 US gal / 4.4 Imp gal
Instrumentation: LCD, Ducati electronics Riding Modes, Power Modes, Ducati Safety Pack (ABS + DTC)
