Ducati Monster 796 (2012) technical specifications

Ducati Monster 796 technical specifications

Ducati Monster 796 is produced in 2012. Engine is Four stroke, 90° “L” twin cylinder, SOHC, desmodromic 2 valves per cylinder, displacement 803 cc / 49.0 cu in , produces power 64 kW / 87 hp @ 8250 rpm and 78.5 Nm / 8.0 kgf-m 58 lb-ft @ 6250rpm. Ducati Monster 796 top speed is 200.4 km/h / 124.5 mph. Ducati Monster 796 weighs 167 kg - 369 lbs / 169 kg -373 lbs ABS version. Ducati Monster 796 has 10 photos.

Technical specifications

+ Add to 'Compare list'
Model: Monster 796
Years: 2012
Engine: Four stroke, 90° “L” twin cylinder, SOHC, desmodromic 2 valves per cylinder
Capacity: 803 cc / 49.0 cu in
Bore x Stroke: 88 x 66 mm
Compression Ratio: 11.0:1
Cooling System: Air cooled
Induction: Siemens electronic fuel injection, 45mm throttle body
Ignition: Marelli electronic
Starting: Electric
Exhaust:: Lightweight 2-1-2 system with catalytic converter with twin lambda probes
Max Power: 64 kW / 87 hp @ 8250 rpm
Max Torque: 78.5 Nm / 8.0 kgf-m 58 lb-ft @ 6250rpm
Clutch: APTC wet multiplate with hydraulic control
Transmission: 6 Speed
Final Drive: Chain; front sprocket 15; rear sprocket 39
Gear Ratio: 1st 32/13, 2nd 30/18, 3rd 28/21, 4th 26/23, 5th 22/22, 6th 24/26
Primary drive: Straight cut gears; ratio 1.85:1
Frame: Tubular steel trellis
Front Suspension: Showa 43mm upside-down forks
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Progressive linkage with fully adjustable Sachs monoshock with piggy back aluminum swing arm
Rear Wheel travel: 148 mm / 5.8 in
Front Brakes: 2 x 320mm Discs, 4 piston calipers
Rear Brakes: Single 245 mm disc, 2 piston caliper
Front Tyre: 120/70 -ZR17
Rear Tyre: 160/55 -ZR17
Rake: 24°
Trail: 87mm / 3.42 in
Wheelbase: 1450 mm / 57.1in
Seat Height: 800 mm / 31.5 in
Dry Weight: 167 kg - 369 lbs / 169 kg -373 lbs ABS version
Wet Weight: 187 kg / 412 lbs
Fuel Capacity: 15 L / 4.0 USgal / 3.3 Imp gal (13.5 L / 3.6 US gal / 3.0 Imp gal ABS version)
Consumption Average: 5.2 L/100 km / 19.1 km/l . 45 US mpg / 54 Imp mpg
Standing ¼ Mile: 12.1 sec
Top Speed: 200.4 km/h / 124.5 mph
Instrumentation: Digital unit displaying: Speedometer, rev counter, clock, scheduled maintenance warning, oil temperature, trip fuel, lap time, warning light for low oil pressure, fuel level, fuel reserve, neutral, turn signals, overrev, immobilizer. Ready for DDA system.
