Ducati Monster 600 (1998) technical specifications

Ducati Monster 600 technical specifications

Ducati Monster 600 is produced in 1998. Engine is Four stroke, 90°“L”twin cylinder, SOHC, desmodromic 2 valves per cylinder, displacement 583 cc / 35.6 cu in , produces power 38.7 kW / 53 hp @ 8250 rpm and 48.00 Nm / 4.9 kgf-m / 35.4 ft-lb @ 7000 rpm. Ducati Monster 600 top speed is 191.9 km/h / 119.2mph. Ducati Monster 600 weighs 174 kg / 383 lbs. Ducati Monster 600 has 2 photos.

Technical specifications

+ Add to 'Compare list'
Model: Monster 600
Years: 1998
Engine: Four stroke, 90°“L”twin cylinder, SOHC, desmodromic 2 valves per cylinder
Capacity: 583 cc / 35.6 cu in
Bore x Stroke: 80 x 58 mm
Cooling System: Air cooled
Compression Ratio: 10.7:1
Lubrication: Wet sump
Engine Oil: Synthetic, 10W/40
Induction: 2 x 38 mm Mikuni carburetors
Spark Plugs: RA 4 HC
Ignition: Analogue CDI (Capacitive Discharge Ign.)
Spark Plug: Champion, RA6HC
Battery: 12V 16Ah
Starting: Electric
Max Power: 38.7 kW / 53 hp @ 8250 rpm
Max Torque: 48.00 Nm / 4.9 kgf-m / 35.4 ft-lb @ 7000 rpm
Clutch: Wet, cable operated
Transmission: 5 Speed
Primary Drive Ratio: 2.28:1 (32/73)
Gear Ratios: 1st 2.500 / 2nd 1.714 / 3rd 1.333 / 4th 1.074 / 5th 0.966:1
Final Drive Ratio: 2.6:1 (15/39)
Final Drive: Chain
Frame: Steel, Trellis frame
Front Suspension: 40 mm Marzocchi inverted telescopic fork
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: boge rising rate monoshock
Rear Wheel Travel: 136 mm / 5.4 in
Front Brakes: Single 320 mm disc, 4 piston caliper
Rear Brakes: Single 245mm disc, 2 piston caliper
Front Tyre: 120/60 VR17
Rear Tyre: 160/60 VR17
Dimensions: Length: 2090 mm / 82.3 in Width: 770 mm / 30.3 in Height: 1060 mm / 41.7 in
Wheelbase: 1430 mm / 56.3 in
Seat Height: 770 mm / 30.3 in
Dry Weight: 174 kg / 383 lbs
Fuel Capacity: 16 L / 4.2 US gal / 3.5 Imp gal
Consumption Average: 5/1 L/100km / 19.7 km/l / 46.3 US mpg / 55.6 Imp mpg
Braking 60 km/h - 0: 12.9 m / 42.3 ft
Braking 100 km/h - 0: 39.3 m / 128.9 ft
Standing ¼ Mile: 12.5 sec / 164.2 km/h / 102 mph
Top Speed: 191.9 km/h / 119.2mph
Colours: Red, Yellow, Black, Silver gray
