Ducati Monster 1200S Black (2020) technical specifications

Ducati Monster 1200S Black is produced in 2020. Engine is Four stroke, Testastretta 11° L-Twin, DOHC, 4 Desmodromically actuated valves per cylinder, displacement 1198 cc / 72.9 cu-in , produces power 147 hp / 108 kW @ 9250 rpm and 124 Nm / 91 lb-ft @ 7750 rpm. Ducati Monster 1200S Black weighs 185 kg / 408 lbs. Ducati Monster 1200S Black has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Monster 1200S Black
Years:	2020
Engine:	Four stroke, Testastretta 11° L-Twin, DOHC, 4 Desmodromically actuated valves per cylinder
Capacity:	1198 cc / 72.9 cu-in
Bore x Stroke:	106 x 67.9 mm
Cooling System:	Liquid cooled
Compression Ratio:	13.0:1
Lubrication:	Wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Induction:	Electronic fuel injection system, 56mm oval throttle bodies with full Ride-by-Wire
Exhaust:	Lightweight 2-1-2 system with catalytic converter and 2 lambda probes, twin stainless steel mufflers with aluminium covers and end caps
Ignition:	Marelli electronic
Starting:	Electric
Max Power:	147 hp / 108 kW @ 9250 rpm
Max Torque:	124 Nm / 91 lb-ft @ 7750 rpm
Clutch:	Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Transmission:	6 Speed with Ducati Quick Shift up & down (DQS)
Final Drive:	Chain, front sprocket Z=15, rear sprocket Z=41
Gear Ratio:	1st 37/15 2nd 30/17 3rd 27/20 4th 24/22 5th 23/24 6th 22/25
Primary Drive:	Straight cut gears, ratio 1.84:1
Frame:	Tubular steel trellis frame attached to the cylinders head
Front Suspension:	48 mm Öhlins fully adjustable USD fork
Front Wheel Travel:	130 mm / 5.1 in
Rear Suspension:	Progressive linkage with fully adjustable Öhlins monoshock, aluminium single-sided swingarm
Rear Wheel Travel:	149 mm / 5.8 in
Front Brakes:	2 x 320 mm Semi-floating discs, radially mounted Monobloc Brembo Evo M50 callipers, 4-pistons, radial pump with Bosch ABS as standard
Rear Brakes:	Single 245mm disc, 2-piston floating calliper with Bosch ABS as standard equipment
Front Tyre:	120/70 - ZR17 Pirelli Diablo Rosso III
Rear Tyre:	190/55 - ZR17 Pirelli Diablo Rosso III
Front wheel:	Y shaped 3-spoke light alloy with ‘S’ graphics, 3.50 in x 17 in
Rear wheel:	Y shaped 3-spoke light alloy with ‘S’ graphics, 6.00 in x 17 in
Wheelbase:	1485 mm / 58.46 in
Rake:	23.3°
Trail:	86.5 mm / 3.4 in
Seat Height:	795 mm - 820 mm / 31.30 in - 32.28 in, adjustable
Dry Weight:	185 kg / 408 lbs
Wet Weight:	211 kg / 465 lbs
Fuel Capacity:	16.5 Litres / 4.36 US gal
