Ducati Hypermotard 1100 EVO SP (2012) technical specifications

Ducati Hypermotard 1100 EVO SP technical specifications

Ducati Hypermotard 1100 EVO SP is produced in 2012. Engine is Four stroke, 90° “L” twin cylinder, SOHC, desmodromic 2 valves per cylinder, displacement 1078 cc / 65.8 cu in , produces power 69.9 kW / 95 hp / @ 7500 rpm and 102.9 Nm / 10.5 kgf-m / 76 lb-ft @ 5750 rpm. Ducati Hypermotard 1100 EVO SP top speed is 220 km/h / 136.7 mph. Ducati Hypermotard 1100 EVO SP weighs 172 kg / 379 lbs. Ducati Hypermotard 1100 EVO SP has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: Hypermotard 1100 EVO SP
Years: 2012
Engine: Four stroke, 90° “L” twin cylinder, SOHC, desmodromic 2 valves per cylinder
Capacity: 1078 cc / 65.8 cu in
Bore x Stroke: 98 x 71.5 mm
Cooling System: Air cooled
Compression Ratio: 10.0:1
Lubrication: Wet sump
Engine Oil: Synthetic, 15W-50
Induction: Fuel Injection, 45 mm throttle body
Exhaust: Lightweight 2-1-2 system with catalytic converter and lambda probe
Ignition: Marelli electronic
Starting: Electric
Max Power: 69.9 kW / 95 hp / @ 7500 rpm
Max Torque: 102.9 Nm / 10.5 kgf-m / 76 lb-ft @ 5750 rpm
Clutch: Dry multiplate with hydraulic control
Transmission: 6 Speed
Final Drive: Chain, front sprocket 15, rear sprocket 42
Primary Drive: Straight cut gears, ratio 1.84:1
Gear Ratio: 1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 24/28
Frame: Tubular steel trellis
Front Suspension: 50mm Marzocchi forks, fully adjustable with DLC
Front Wheel Travel: 195 mm / 7.5 in
Rear Suspension: Progressive linkage with fully adjustable Öhlins monoshock. Aluminium single-sided swingarm .
Rear Wheel Travel: 156 mm / 6.1 in
Front Brakes: 2 x 305 mm Semi-floating discs, radially mounted Brembo Monobloc calipers 4-pistons, 2-pads
Rear Brakes: Single 245mm disc, 2-piston caliper
Front Wheel: 5-Spoke in light alloy 3.50 x 17
Rear Wheel: 5-Spoke light alloy 5.50 x 17
Front Tyre: 120/70 ZR 17, Pirelli Diablo Rosso
Rear Tyre: 180/55 ZR 17, Pirelli Diablo Rosso
Rake: 24°
Trail: 100 mm / 3.9 in
Wheelbase: 1455 mm / 57.28 in
Seat Height: 845 mm / 33.2 in
Dry Weight: 172 kg / 379 lbs
Fuel Capacity: 12.4 Litres / 3.3 US gal / 2.7 Imp gal
Consumption Average: 4.8 L/100 km / 20.8 km/l / 48.9 US mpg / 58.8 Imp mpg
Standing ¼ Mile: 12.0 sec / 178.1 km/h / 110.7 mph
Standing 1000 m: 23.3 sec / 201.3 km/h / 125.1 mph
Top Speed: 220 km/h / 136.7 mph
