Ducati Diavel 1260 Lamborghini (2021) technical specifications

Ducati Diavel 1260 Lamborghini technical specifications

Ducati Diavel 1260 Lamborghini is produced in 2021. Engine is Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark, displacement 1262 cc / 77 cu in , produces power 159 hp / 117 kW @ 9500 rpm and 128.9 Nm / 95 lb-ft @ 7500 rpm. Ducati Diavel 1260 Lamborghini weighs 214 kg / 481 lbs. Ducati Diavel 1260 Lamborghini has 10 photos.

Technical specifications

+ Add to 'Compare list'
Model: Diavel 1260 Lamborghini
Years: 2021
Production: 630 units
Engine: Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark
Capacity: 1262 cc / 77 cu in
Bore x Stroke: 106 x 71.5 mm
Cooling System: Liquid cooled
Compression Ratio: 13.0:1
Exhaust: Stainless steel pipes and single muffler with twin tail pipes, catalytic converter and 2 lambda probes
Induction: Bosch electronic fuel injection system, Øeq 56 mm elliptical throttle bodies with Ride-by-Wire system
Ignition: Electronic
Starting: Electric
Max Power: 159 hp / 117 kW @ 9500 rpm
Max Torque: 128.9 Nm / 95 lb-ft @ 7500 rpm
Clutch: Slipper and self-servo wet multiplate clutch with hydraulic control
Transmission: 6-Speed with Ducati Quick Shift up/down Evo (DQS)
Final Drive: Chain, Front sprocket Z15, Rear sprocket Z43
Primary Drive: Straight cut gears, Ratio 1.84:1
Gear Ratios: 1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 22/25
Frame: Tubular steel trellis frame
Front Suspension: 48 mm USD Öhlins adjustable fork, TiN treatment
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Öhlins fully adjustable monoshock, aluminium casted single-sided swingarm
Rear Wheel Travel: 130 mm / 5.1 in
Front Brakes: 2 x 320mm semi-floating discs, Radially mounted Brembo monobloc 4-piston M50 callipers, PR16/19 radial master cylinder
Rear Brakes: Single 265mm disc, 2-piston Brembo floating calliper
ABS: Bosh Cornering ABS Evo
Front Wheel: Light alloy, forged and machined, 3.50 x 17
Rear Wheel: Light alloy, forged and machined, 8.00 x 17
Front Tyre: 120/70 ZR17 Pirelli Diablo Rosso III
Rear Tyre: 240/45 ZR17 Pirelli Diablo Rosso III
Rake: 27°
Trail: 120 mm / 4.7 in
Wheelbase: 1600 mm / 63.0 in
Seat Height: 780 mm / 30.7 in
Dry Weight: 214 kg / 481 lbs
Wet Weight: 246 kg / 542 lbs
Fuel Capacity: 17 Litres / 4.5 US gal
Instrumentation: 3.5 in TFT colour display and dedicated warning light display
