Ducati Diavel 1260 (2020) technical specifications

Ducati Diavel 1260 is produced in 2020. Engine is Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark, displacement 1262 cc / 77 cu in , produces power 159 hp / 117 kW @ 9500 rpm and 128.9 Nm / 95 lb-ft @ 7500 rpm. Ducati Diavel 1260 weighs 214 kg / 481 lbs. Ducati Diavel 1260 has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Diavel 1260
Years:	2020
Engine:	Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark
Capacity:	1262 cc / 77 cu in
Bore x Stroke:	106 x 71.5 mm
Cooling System:	Liquid cooled
Compression Ratio:	13.0:1
Exhaust:	Stainless steel pipes and single muffler with twin tail pipes, Catalytic converter and 2 lambda probes
Induction:	Electronic fuel injection system, Øeq 56 mm elliptical throttle bodies with Ride-by-Wire system
Emission:	Euro4
Ignition:	Electronic
Starting:	Electric
Max Power:	159 hp / 117 kW @ 9500 rpm
Max Torque:	128.9 Nm / 95 lb-ft @ 7500 rpm
Clutch:	Slipper and self-servo wet multiplate clutch with hydraulic control
Transmission:	6-Speed
Final Drive:	Chain, Front sprocket Z15, Rear sprocket Z43
Primary Drive:	Straight cut gears, Ratio 1.84:1
Gear Ratios:	1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 22/25
Frame:	Tubular steel trellis frame
Front Suspension:	50mm USD adjustable fork
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Single shock absorber, adjustable preload and rebound, remote reservoir. Single sided cast/trellis frame swingarm, natural anodized and brushed swingarm
Rear Wheel Travel:	110 mm / 4.33 in
Front Brakes:	2 x 320mm semi-floating discs, Radially mounted Brembo monobloc 4-piston M4.32 callipers, PR18/19 radial master cylinder.
Rear Brakes:	Single 265mm disc, 2-piston Brembo floating calliper
ABS:	Cornering ABS Evo
Front Wheel:	Light alloy, cast, 3.50 x 17
Rear Wheel:	Light alloy, cast, 8.00 x 17
Front Tyre:	120/70 ZR17 Pirelli Diablo Rosso II
Rear Tyre:	240/45 ZR17 Pirelli Diablo Rosso II
Rake:	27°
Trail:	120 mm / 4.7 in
Wheelbase:	1600 mm / 63.0 in
Seat Height:	780 mm / 30.7 in
Dry Weight:	214 kg / 481 lbs
Wet Weight:	244 kg / 538 lbs
Fuel Capacity:	17 Litres / 4.5 US gal
Instrumentation:	3.5in TFT colour display and dedicated warning light display
