Ducati 748R (2002) technical specifications

Ducati 748R technical specifications

Ducati 748R is produced in 2002. Engine is Four stroke, 90°“L”twin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven, displacement 748 cc / 45.6 cu in , produces power 77 kW / 105 hp @ 1100 rpm and 75 Nm / 7.65 kg-m /55.3 ft-lb @ 8700 rpm. Ducati 748R top speed is 250 km/h / 155 mph. Ducati 748R weighs 198 kg / 436 lbs. Ducati 748R has 2 photos.

Technical specifications

+ Add to 'Compare list'
Model: 748R
Years: 2002
Engine: Four stroke, 90°“L”twin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven
Capacity: 748 cc / 45.6 cu in
Bore x Stroke: 88 x 61.5 mm
Cooling System: Liquid cooled
Compression Ratio: 11.6:1
Lubrication: Wet sump
Engine Oil: Semi-Synthetic, 10W/40
Oil Capacity: 3.5 L / 3.7 US qt / 3.1 Imp qt
Induction: Weber I.A.W. CPU 1.6M
Spark Plug: Champion RA59
Ignition: Electronic
Battery: 12V 16Ah
Starting: Electric
Max Power: 77 kW / 105 hp @ 1100 rpm
Max Torque: 75 Nm / 7.65 kg-m /55.3 ft-lb @ 8700 rpm
Clutch: Dry, multi-plate, hydraulic control
Transmission: 6 Speed
Primary Drive Ratio: 2:1 (31/62)
Gear Ratios: 1st 2.466 / 2nd 1.765 / 3rd 1.400 / 4th 1.182 / 5th 1.043 / 6th 0.958:1
Final Drive Ratio: 2.64:1 (14/37)
Final Drive: Chain, 520 VL4 - 5/8" x 1/4"
Frame: Trestle type constructed of "ALS 450" steel alloy
Front Suspension: Inverted type, 43 mm diameter stanchions, Öhlins, fully adjustable, TiN coated
Front Wheel Travel: 127 mm / 5.0 in
Rear Suspension: Progressive linkage with adjustable monoshock, Öhlins
Rear Wheel Travel: 130 mm / 5.1 in
Front Brakes: 2 x 320mm Discs, 4 piston calipers, Brembo
Rear Brakes: Single 220 mm disc, 1 piston caliper, Brembo
Front Tyre: 120/60 ZR17
Rear Tyre: 180/55 ZR17
Rake: 24.5°
Dimensions: Length: 2050 mm / 80.7 in Width: 685 mm / 27.0 in Height: 1090 mm / 42.9 in
Wheelbase: 1410 mm / 55.5 in
Seat Height: 790 mm / 31.1 in
Ground Clearance: 150 mm / 5.9 in.
Handlebar Height: 850 mm / 33.5 in.
Dry Weight: 198 kg / 436 lbs
Fuel Capacity: 17 Litres / 4.5 US gal / 3.7 Imp gal
Consumption Average: 5.8 L/100 km / 17.3 km/l / 40.7 US mpg / 48.9 Imp mpg
Braking 60 km/h - 0: 13.3 m / 43.6 ft
Braking 100 km/h - 0: 37.7 m / 123.7 ft
Standing ¼ Mile: 11.2 sec / 204 km/h / 127 mph
Top Speed: 250 km/h / 155 mph
