Ducati 175 Americano (1957-60) technical specifications
Ducati 175 Americano is produced in 1957-60. Engine is Four stroke, single cylinder, SOHC, shaft and bevel gear driven, 2 valves per cylinder, displacement 174.5 cc / 10.6 cu in , produces power 8.2 kW / 11 hp @ 7500 rpm. Ducati 175 Americano top speed is 110 km/h / 68 mph. Ducati 175 Americano weighs 118 kg / 260 lbs. Ducati 175 Americano has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | 175 Americano |
| Years: | 1957-60 |
| Engine: | Four stroke, single cylinder, SOHC, shaft and bevel gear driven, 2 valves per cylinder |
| Capacity: | 174.5 cc / 10.6 cu in |
| Bore x Stroke: | 62 x 57.8 mm |
| Compression Ratio: | 7:1 |
| Cooling System: | Air cooled |
| Induction: | Dell'Orto MB22B carburetor |
| Ignition: | 6V 40W generator |
| Spark Plug: | Marelli CW250A |
| Starting: | Kick |
| Max Power: | 8.2 kW / 11 hp @ 7500 rpm |
| Clutch: | Multi wet plate, wet |
| Primary Drive: | 2.522:1 |
| Transmission: | 4 Speed |
| Final Drive: | 3.066:1 |
| Gear Ratios: | 1st 2.75 / 2nd 1.65 / 3rd 1.18 / 4th 0.97:1 |
| Frame: | Single cradle tubular frame |
| Front Suspension: | Hydraulic telescopic fork |
| Rear Suspension: | Swingarm, dual shocks, 3-way adjustable |
| Front Brakes: | Drum, full aluminium, 180 mm |
| Rear Brakes: | Drum, full aluminium, 160 mm |
| Front Tyre: | 2.50 -18 |
| Rear Tyre: | 2.75 -18 |
| Dimensions: | Length: 1980 mm / 78.0 in Height: 1040 mm / 40.9 in |
| Wheelbase: | 1320 mm / 52 in |
| Seat Height: | 800 mm / 31.5 in |
| Dry Weight: | 118 kg / 260 lbs |
| Fuel Capacity: | 17 L / 4.5 US gal / 3.7 Imp gal |
| Top Speed: | 110 km/h / 68 mph |
