Ducati 160 Monza Junior (1964-67) technical specifications

Ducati 160 Monza Junior is produced in 1964-67. Engine is Air cooled, four stroke, single cylinder, OHC, 2 valve per cylinder, bevel gear driven, displacement 156 cc / 9.5 cu in , produces power 6.9 kW / 9.5 hp @ 8000 rpm. Ducati 160 Monza Junior top speed is 1964-65: 102 km/h / 63 mph 1966-67: 113 km/h / 71 mph. Ducati 160 Monza Junior weighs 1964: 106 kg / 234 lbs 1965-67: 108 kh / 238 lbs. Ducati 160 Monza Junior has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	160 Monza Junior
Years:	1964-67
Engine:	Air cooled, four stroke, single cylinder, OHC, 2 valve per cylinder, bevel gear driven
Capacity:	156 cc / 9.5 cu in
Bore x Stroke:	61 x 52 mm
Compression Ratio:	8.2:1
Cooling System:	Air cooled
Lubrication:	Dry sump
Induction:	Dell'Orto UB22BS
Ignition:	Coil, 6V 28W generator
Starting:	Kick
Battery:	SAFA 7Ah
Max Power:	6.9 kW / 9.5 hp @ 8000 rpm
Clutch:	Multi-plate, wet
Primary Drive Ratio:	3.000:1
Transmission:	4 Speed
Final Drive:	Chain
Gear Ratios:	1st 2.75 / 2nd 1.65 / 3rd 1.18 / 4th 0.97:I
Final Drive Ratio:	2.875:1
Frame:	Single cradle
Front Suspension:	Telescopic front fork, hydraulic damping, Marzocci
Rear Suspension:	Swingarm, dua shocks, 3-way adjustable
Front Brakes:	158 mm Drum
Rear Brakes:	136 mm Drum
Front Tyre:	2.75 -16
Rear Tyre:	3.25 -16
Dimensions:	Length: 1980 mm / 78.0 in Height: 930 mm / 36.6 in
Wheelbase:	1330 mm / 52.4 in
Seat Height:	760 mm / 29.9 in
Dry Weight:	1964: 106 kg / 234 lbs 1965-67: 108 kh / 238 lbs
Fuel Capacity:	13 L / 3.4 US gal / 2.9 Imp gal
Top Speed:	1964-65: 102 km/h / 63 mph 1966-67: 113 km/h / 71 mph
