Confederate Combat Wraith (2021) technical specifications

Confederate Combat Wraith is produced in 2021. Engine is Four stroke, S&S X-Wedge 56° V-twin, with one-piece forged crankshaft, two valves per cylinder, toothed belt camshaft drive, and machined 6061 aluminum billet crankcase, displacement 2163 cc / 132 cu-in - 1917 cc / 117cu-in optional , produces power 108 hp / 80.5 kW @ 5000 rpm and 195 Nm / 144 lb-ft @ 4800 rpm. Confederate Combat Wraith wet weight is 254 kg / 560 lbs. Confederate Combat Wraith has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Combat Wraith
Years:	2021
Production:	21
Engine:	Four stroke, S&S X-Wedge 56° V-twin, with one-piece forged crankshaft, two valves per cylinder, toothed belt camshaft drive, and machined 6061 aluminum billet crankcase
Capacity:	2163 cc / 132 cu-in - 1917 cc / 117cu-in optional
Cooling System:	Air / oil cooled
Induction:	Closed-loop Delphi electronic fuel injection and engine management system, with single injector per cylinder, and 2 x 51mm S&S throttle body
Starting:	Electric
Max Power:	108 hp / 80.5 kW @ 5000 rpm
Max Torque:	195 Nm / 144 lb-ft @ 4800 rpm
Clutch:	Hydraulically operated dry clutch by Bandit Machine Works
Transmission:	5-speed proprietary stacked gearbox with Andrews gears
Chassis:	Machined aluminum monocoque, massive 7 in curved Wraith backbone containing fuel load
Foot Controls:	Proprietary interlinked shifting mechanism and Beringer rear and forward position interlinked rear braking system
Front Suspension:	Double-wishbone parallelogram CNC 6061 aluminum fork with tubular aluminium struts and direct-action, Racetech monoshock fully-adjustable for high and low speed compression and rebound damping
Front Wheel Travel:	114 mm /4.35 in
Rear Suspension:	CNC Aluminum swingerarm with cantilever Racetech monoshock rear suspension, offering fully adjustable two-speed compression and rebound damping
Rear Wheel Travel:	140 mm / 5.50 in
Front Brakes:	Quad Disk 4D Piston 2 x 230 mm Beringer floating Aeronal cast iron discs with four-piston Beringer radially-mounted Aerotec calipers
Rear Brakes:	Single 240 mm cross-drilled Aeronal stainless steel disc with two-piston Beringer caliper
Front Wheel:	19in BST carbon
Rear Wheel:	17in BST carbon disc
Front Tyre:	120/70ZR19 Pirelli Diablo Rosso III
Rear Tyre:	240/45ZR17 Pirelli Diablo Rosso III
Rake:	27°
Trail:	100 mm / 4 in
Wheelbase:	1587.5 mm / 62.5 in
Seat Height:	749 mm / 29.5 in
Wet Weight:	254 kg / 560 lbs
Fuel Capacity:	17 Litres / 4.5 US gal
