CCM Classic Tracker (2022) technical specifications

CCM Classic Tracker technical specifications

CCM Classic Tracker is produced in 2022. Engine is Four-stroke, single cylinder, displacement 600 cc / 36.6 cu-in , produces power 55 hp / 40kW and 58 Nm / 42.7 lb-ft @ 5500 rpm. CCM Classic Tracker weighs 145 kg / 319.6 lbs. CCM Classic Tracker has 9 photos.

Technical specifications

+ Add to 'Compare list'
Model: Classic Tracker
Years: 2022
Engine: Four-stroke, single cylinder
Capacity: 600 cc / 36.6 cu-in
Bore x Stroke: 100 x 76.5 mm
Compression Ratio: 12.0:1
Cooling System: Liquid cooled
Exhaust: Twin single side high level exhausts
Induction: Fuel injection, Mikuni D45
Starting: Electric
Max Power: 55 hp / 40kW
Max Torque: 58 Nm / 42.7 lb-ft @ 5500 rpm
Clutch: Multiple-disc, wet, hydraulic control
Transmission: 6 Speed
Final Drive: Chain
Frame: High strength steel, hand tig welded
Front Suspension: Telescopic forks, adjustable
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Single shock, adjustable
Rear Wheel Travel: 120 mm / 4.7 in
Front Brakes: Single 320mm disc
Rear Brakes: Single 240mm disc
Front Tyre: 19 in road-legal Maxxis flattrack tyres
Rear Tyre: 19 in road-legal Maxxis flattrack tyres
Rake: 26°
Trail: 118 mm / 4.6 in
Dimensions: Length 2145 mm / 84.4 in Height 1130 mm / 44.8 in
Wheelbase: 1455 mm / 57.2 in
Seat Height: 830 mm / 32.6 in
Dry Weight: 145 kg / 319.6 lbs
Fuel Capacity: 14 Litres / 3.7 US gal
