Technical specifications
|
| Model: |
Elefant 900AC CAT |
| Years: |
1994 |
|
Engine:
|
Four stroke, 90° “L” twin cylinder, SOHC, desmodromic 2 valve per cylinder
|
|
Capacity:
|
904 cc / 55.1 cu-in
|
|
Bore x Stroke:
|
92 x 68 mm
|
|
Cooling System:
|
Air cooled
|
|
Compression Ratio:
|
9.2:1
|
|
Induction:
|
Mikuni BDST 38 carburetors
|
|
Ignition:
|
Marelli electronic inductive discharge
|
|
Starting:
|
Electric
|
|
Max Power:
|
95 hp / 70 kW @ 8500 rpm
|
|
Max Torque:
|
78 Nm / 57.5 lb-ft @ 5250 rpm
|
|
Clutch:
|
Dry Multi-disc
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Double steel tubular cradle
|
|
Front Suspension:
|
45mm Showa upside down telescopic forks
|
|
Rear Suspension:
|
Rising rate box, monoshock adjustable for preload
|
|
Front Brakes:
|
2x 282mm discs 4 piston calipers
|
|
Rear Brakes:
|
Single 240mm disc 4 piston caliper
|
|
Front Tyre:
|
100/90-19
|
|
Rear Tyre:
|
140/80-17
|
|
Dimensions:
|
Length 2295 mm / 90.3 in Width 860 mm / 33.8 in Height 970 mm / 38.1 in
|
|
Wheelbase:
|
1570 mm / 61.8 in
|
|
Seat Height:
|
857 mm / 33.7 in
|
|
Ground Clearance:
|
260 mm / 10.2 in
|
|
Dry Weight:
|
204 kg / 449.7 lbs
|
|
Fuel Capacity:
|
22 Litres / 5.8 US gal
|
|
Consumption Average:
|
38.0 mpg
|
|
Standing ¼ Mile:
|
13.2 sec / 95.5 mph
|
|
Top Speed:
|
183.4 km/h / 114. mph
|
|
Road Test:
|
Motosprint 1993
|
