Cagiva Elefant 750 (1989) technical specifications

Cagiva Elefant 750 technical specifications

Cagiva Elefant 750 is produced in 1989. Engine is Four stroke, 90° “L”twin cylinder, SOHC, desmodromic 2 valve per cylinder, displacement 748 cc / 45.6 cu-in , produces power 60.5 hp / 44.5 kW @ 8000 rpm (rear tyre 52.9 hp @ 7250 rpm) and 47 ft-lb @ 5500 rpm. Cagiva Elefant 750 top speed is 174 km/h / 108 mph. Cagiva Elefant 750 weighs 191 kg / 421 lbs. Cagiva Elefant 750 has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: Elefant 750
Years: 1989
Engine: Four stroke, 90° “L”twin cylinder, SOHC, desmodromic 2 valve per cylinder
Capacity: 748 cc / 45.6 cu-in
Bore x Stroke: 88 x 61.5 mm
Cooling System: Air cooled
Compression Ratio: 9.3:1
Induction: Bing 34/32/375
Ignition: Kokusan
Starting: Electric
Max Power: 60.5 hp / 44.5 kW @ 8000 rpm (rear tyre 52.9 hp @ 7250 rpm)
Max Power Rear Tyre: 52.9 hp @ 7250 rpm
Max Torque: 47 ft-lb @ 5500 rpm
Transmission: 5 Speed
Final Drive: Chain
Front Suspension: 41mm Marzocchi forks
Rear Suspension: Öhlins rising-rate swingarm
Front Brakes: Single 260mm disc 4 piston caliper
Rear Brakes: Single 240mm disc 2 piston caliper
Front Tyre: 90/90-21
Wheelbase: 1520 mm / 59.8 in
Seat Height: 900 mm / 35.4 in
Rear Tyre: 130/90-17
Dry Weight: 191 kg / 421 lbs
Wet Weight: 213.0 kg / 469 lbs
Fuel Capacity: 19 Litres / 5.0 US gal
Top Speed: 174 km/h / 108 mph
Road Test: Adventure Group test Motosprint 1988 Adventure Group Test Motosprint 1989
