Buell / EBR Buell Hammerhead 1190 (2023) technical specifications

Buell / EBR Buell Hammerhead 1190 technical specifications

Buell / EBR Buell Hammerhead 1190 is produced in 2023. Engine is Four stroke, 72° V-Twin, displacement 1190 cc / 72.6 cu-in , produces power 138 kW / 185 hp @ 10600 rpm and 137.8 Nm / 101.6 lb-ft @ 8200 rpm. Buell / EBR Buell Hammerhead 1190 wet weight is 188 kg / 414 lbs - no fuel. Buell / EBR Buell Hammerhead 1190 has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: Buell Hammerhead 1190
Years: 2023
Engine: Four stroke, 72° V-Twin
Capacity: 1190 cc / 72.6 cu-in
Bore x Stroke: 106 x 67.5 mm
Cooling System: Liquid cooled
Compression Ratio: 13.4 :1
Induction: Electronic Fuel injection with 2 port injectors and 2 showerhead injectors
Starting: Electric
Exhaust: Primary + Secondary
Max Power: 138 kW / 185 hp @ 10600 rpm
Max Torque: 137.8 Nm / 101.6 lb-ft @ 8200 rpm
Transmission: 6 Speed
Primary Drive Gear Drive: 36/65
Final Drive: 520 Z-ring chain, 16/41
Gear Ratio: 1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96
Clutch: Hydraulic actuation, vacuum operated slipper
Frame: Aluminum frame with integral fuel reservoir
Swingarm: Optimized stiffness aluminum
Front Suspension: Showa, inverted big piston front forks
Rear Suspension: Showa, single shock without linkage
Front Brakes: 386mm Single perimeter rotor, 8 piston inside-out caliper
Rear Brakes: Single 220mm disc, 2-piston Hayes performance brakes caliper
Front Wheel: 17 x 3.5 Aluminum
Rear Wheel: 17 x 6.0 Aluminum
Front Tyre: 120/70 ZR-17 Pirelli Diablo Rosso Corsa
Rear Tyre: 190/55 ZR-17 Pirelli Diablo Rosso Corsa
Rake: 22.4°
Trail: 96.5 mm / 3.8 in
Lean Angle: 48°
Dimensions: Length: 2040 mm / 80.3 in Width: 810 mm / 31.9 in Height: 1087 mm / 42.8 in
Seat Height: 826 mm / 32.5 in
Ground Clearance: 120 mm / 4.7in
Wet Weight: 188 kg / 414 lbs - no fuel
Fuel Capacity: 17 Litres / 4.5 US gal
