BMW R nineT 100th Anniversary (2023) technical specifications

BMW R nineT 100th Anniversary is produced in 2023. Engine is Four stroke, two cylinder horizontally opposed Boxer, two camshafts and four radially aligned valves per cylinder, central counter balancer shaft., displacement 1170 cc / 71.4 cub in , produces power 80 kW /109 hp @ 7250 rpm and 116 Nm / 11.8 kgf-m / 85.6 lb-ft @ 6000 rpm. BMW R nineT 100th Anniversary wet weight is 221 kg / 487.2 lbs. BMW R nineT 100th Anniversary has 7 photos.

Technical specifications

+ Add to 'Compare list'

Model:	R nineT 100th Anniversary
Years:	2023
Production:	1923 units
Engine:	Four stroke, two cylinder horizontally opposed Boxer, two camshafts and four radially aligned valves per cylinder, central counter balancer shaft.
Capacity:	1170 cc / 71.4 cub in
Bore x Stroke:	101 x 73 mm
Cooling System:	Air/Oil cooled
Compression Ratio:	12.0:1
Lubrication:	Wet sump
Induction:	Electronic intake pipe injection / digital engine management with overrun cutoff, twin-spark ignition
Emission Control:	Controlled 3-way catalytic converter, exhaust emission standards EU-5
Fuel:	Unleaded super (premium), octane number 95-98 (RON) (rated output at 98 RON)
Alternator:	Three-phase alternator with 720 Watt nominal power
Battery:	12 V / 12 Ah, maintenance-free
Starting:	Electric
Max Power:	80 kW /109 hp @ 7250 rpm
Max Torque:	116 Nm / 11.8 kgf-m / 85.6 lb-ft @ 6000 rpm
Clutch:	Single dry plate clutch, hydraulically operated
Transmission:	6-speed, claw-shifted transmission with helical-cut splines
Final Drive:	Shaft
Frame:	Four-part frame concept with front frame and three-part rear frame, load-bearing engine-gearbox unit, rear-seat frame removeable for one-up riding
Front Suspension:	46 mm upside-down telescopic forks
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring strut, spring preload fully adjustable by hook wrench, adjustable rebound-stage damping
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	2 x 320 mm discs, 4 piston calipers
Rear Brakes:	Single 265 mm disc, 2 piston floating caliper
ABS:	BMW Motorrad ABS Pro
Wheels:	Spoked
Front Rim:	3.50 x 17
Rear Rim:	5.50 x 17
Front Tyre:	120/70 - ZR17
Rear Tyre:	180/55 - ZR17
Castor:	107.9 mm / 4.2 in
Steering Head Angle:	63.2 °
Dimensions:	Length 2105 mm / 82.9 in Width 865 mm / 34.0 in Height 1240 mm / 48.8 in
Wheelbase:	1487 mm / 58.5 in
Seat Height:	805 mm / 31.7 in
Inner Leg Curve:	1785 mm / 70.3 in
Wet Weight:	221 kg / 487.2 lbs
Fuel Capacity:	18 Litres / 4.7 US gal
