BMW R 66 (1938-41) technical specifications
BMW R 66 is produced in 1938-41. Engine is Four stroke, single cylinder vertical, SV, displacement 595 cc / 36.3 cu in , produces power 22.4 kW / 30 hp @ 5300 rpm. BMW R 66 wet weight is 187 kg / 411 lbs. BMW R 66 has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | R 66 |
| Years: | 1938-41 |
| Engine: | Four stroke, single cylinder vertical, SV |
| Capacity: | 595 cc / 36.3 cu in |
| Bore x Stroke: | 69.8 x 78 mm |
| Compression Ratio: | 6.8:1 |
| Cooling System: | Air cooled |
| Induction: | 1 x Amal 6/420 S carburetor |
| Ignition: | Battery ignition |
| Starting: | Kick |
| Clutch: | Single plate, dry |
| Max Power: | 22.4 kW / 30 hp @ 5300 rpm |
| Transmission: | 4 Speed |
| Final Drive: | Shaft |
| Gear Ratio: | 1st 3.6 / 2nd 2.28 / 3rd 1. 7 / 4th 1.3 |
| Frame: | Twin loop steel tubular frame |
| Front Suspension: | Telescopic fork |
| Rear Suspension: | Telescopic suspension |
| Front Brakes: | ∅200mm Drum |
| Rear Brakes: | ∅200mm Drum |
| Front Tyre: | 3.50 -19 |
| Rear Tyre: | 3.50 -19 |
| Wet Weight: | 187 kg / 411 lbs |
| Fuel Capacity: | 14 liters / 3.6 US gal |
