BMW R 60/2 (1966) technical specifications

BMW R 60/2 technical specifications

BMW R 60/2 is produced in 1966. Engine is Four stroke, two cylinder horizontally opposed Boxer, pushrod operated 2 valves per cylinder., displacement 594 cc / 36.2 cu in , produces power 22.4 kW / 30 hp @ 5800 rpm and 49 Nm / 5.0 kgf-m / 36 ft lb @ 5000 rpm. BMW R 60/2 wet weight is 195 kg / 430 lbs. BMW R 60/2 has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: R 60/2
Years: 1966
Engine: Four stroke, two cylinder horizontally opposed Boxer, pushrod operated 2 valves per cylinder.
Capacity: 594 cc / 36.2 cu in
Bore x Stroke: 72 x 73 mm
Compression Ratio: 7.5:1
Cooling System: Air cooled
Induction: 2 x Type Bing 1/24/151 - 1/24/152
Ignition: Battery ignition
Starting: Kick
Clutch: Single plate, saucer spring, dry
Max Power: 22.4 kW / 30 hp @ 5800 rpm
Max Torque: 49 Nm / 5.0 kgf-m / 36 ft lb @ 5000 rpm
Transmission: 4 Speed
Final Drive: Shaft
Gear Ratio: 1st 4.17 / 2nd 2.73 / 3rd 1.94 / 4th 1.54:
Front Suspension: Telescopic hydraulic forks
Front Wheel Travel: 208 mm / 8.2"
Rear Suspension: Long swinging arm with strut
Rear Wheel Travel: 125 mm / 4.9"
Front Brakes: ∅200mm Drum
Rear Brakes: ∅200mm drum
Front Tyre: 3.50 - S18
Rear Tyre: 3.50 - S18
Wet-Weight: 195 kg / 430 lbs
Fuel Capacity: 17 L / 4.49 US gal.
