BMW R 1300RS (2025) technical specifications

BMW R 1300RS is produced in 2025. Engine is Four stroke, two cylinder horizontally opposed Boxer, with two overhead spur gear driven camshafts, a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder, intake 44mm, outlet 35.6 mm, displacement 1300 cc / 79 cu-in , produces power 107kW / 145hp @ 7750 rpm and 149 Nm / 110 lb-ft @ 6500 rpm. BMW R 1300RS wet weight is 245 kg / 540 lbs. BMW R 1300RS has 7 photos.

Technical specifications

+ Add to 'Compare list'

Model:	R 1300RS
Years:	2025
Engine:	Four stroke, two cylinder horizontally opposed Boxer, with two overhead spur gear driven camshafts, a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder, intake 44mm, outlet 35.6 mm
Capacity:	1300 cc / 79 cu-in
Bore x Stroke:	106.5 x 73 mm
Compression Ratio:	13.3:1
Cooling System:	Liquid / Air cooled
Emission:	Closed-loop 3-way catalytic converter, EU5+
Induction:	Electronic intake pipe injection, 52mm ? throttle valve
Fuel:	Unleaded super, octane number 95 (RON)
Engine Control:	BMS-O
Battery:	12 V / 10Ah, maintenance-free
Starting:	Electric
Max Power:	107kW / 145hp @ 7750 rpm
Max Torque:	149 Nm / 110 lb-ft @ 6500 rpm
Clutch:	Wet clutch with anti-hopping function, hydraulically activated
Transmission:	Claw-shift 6-speed gearbox
Final Drive:	Shaft
Primary Ratio:	1.479
Gear Ratios:	1st 2.438 2nd 1.714 3rd. 1.296 4th 1.059 5th 0.906 6th 0.794
Secondary Ratio:	2.818
Frame:	Steel, two-section with bolt on rear frame, load bearing engine
Front Suspension:	47 mm Upside down fork
Front Wheel Travel:	140 mm / 5.5 in
Rear Suspension:	Cast aluminium single-sided swing arm with BMW Motorrad EVO Paralever; WAD strut (travel-related damping), spring
Rear Wheel Travel:	130 mm / 5.1 in
Front Brakes:	2 x 310mm floating discs, 4-piston radial brake calipers
Rear Brakes:	Single 285mm disc, 2-piston floating caliper
ABS System:	BMW Motorrad Integral ABS Pro (full-integral, lean angle optimized)
Wheels:	Cast light alloy
Front Wheel:	3.50 x 17″
Rear Wheel:	6.00 x 17″
Front Tyre:	120/70 ZR17
Rear Tyre:	190/55 ZR17
Castor:	122.5 mm / 4.8 in
Steering Angle:	64?
Dimensions:	Length 2138 mm / 84.2 in Width 846 mm / 33.3 in
Wheelbase:	1523 mm / 60 in
Seat Height:	790/815 mm / 31.1/32.1 in
Wet Weight:	245 kg / 540 lbs
Fuel Capacity:	17 Litres / 4.5 US gal
