BMW R 1200GS LC Adventure (2016) technical specifications

BMW R 1200GS LC Adventure technical specifications

BMW R 1200GS LC Adventure is produced in 2016. Engine is Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder, intake 40mm, outlet 34 mm, displacement 1170 cc / 71.4 cub in. , produces power 92 kW / 125 hp @ 7750 rpm and 125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm. BMW R 1200GS LC Adventure weighs 220 kg / 485 lbs. BMW R 1200GS LC Adventure has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: R 1200GS LC Adventure
Years: 2016
Engine: Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder, intake 40mm, outlet 34 mm
Capacity: 1170 cc / 71.4 cub in.
Bore x Stroke: 101 x 73 mm
Cooling System: Liquid / Air cooled
Compression Ratio: 12.5:1
Induction: Throttle valve 52 mm Carburetion BMS-X Emission control Closed-loop 3-way catalytic converter
Fuel: Premium unleaded (95 RON)
Ignition: BMS-K
Alternator: Three-phase alternator 620 W (nominal power)
Battery: 12 V / 11.8 maintenance-free
Starting: Electric
Electrical system: Headlight H7W / LED (SA) Starter 0.9 kW
Exhaust management: Fully-controlled three-way catalytic converter
Max Power: 92 kW / 125 hp @ 7750 rpm
Max Torque: 125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm
Clutch: Anti-hopping wet clutch
Transmission: 6 Speed
Final Drive: Shaft
Gear Ratios: 1st 2.438 / 2nd 1.714 / 3rd 1.296 / 4th 1.059 / 5th 0.943 / 6th 0.848:1
Transmission Ratio: 2.91:1
Frame: Tubular steel bridge frame, engine self-supporting
Front Suspension: BMW Motorrad Telelever; diameter 37 mm, central spring strut
Front Wheel Travel: 210 mm / 8.3 in.
Rear Suspension: Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring preload hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel
Rear Wheel Travel: 220 mm / 8.7 in
Front Brakes: 2x 305mm Hydraulically actuated twin disc brake, BMW Motorrad Integral ABS (standard, part intergal, disengageable)
Rear Brakes: Single 275mm disc 2 piston caliper, BMW Motorrad Integral ABS (standard, part intergal, disengageable)
Front Wheel: Cast aluminum wheels laced wire spokes
Rear Wheel: Cast aluminum wheels laced wire spokes
Front Rim: 3.00 x 19
Rear Rim: 4.50 x 17
Front Tyre: 120/70 R19
Rear Tyre: 170/60 R17
Wheel castor: 99.6 mm / 3.9 in
Steering Head Angle: 64.5 °
Dimensions: Height 1450 mm / 57.1 in Width 953 mm / 37.5 in Length 2210 mm / 87.0 in
Wheelbase: 1507 mm / 59.3 in
Seat Height: 890 mm - 910 mm / 35.0 in - 35.8 in
Dry Weight: 220 kg / 485 lbs
Wet Weight: 260 kg / 573 lbs
Fuel Capacity: 30 Litres / 7.9 US gal
Reserve: 4 Litres / 1.1 US gal
