BMW R 12 nineT (2024) technical specifications

BMW R 12 nineT is produced in 2024. Engine is Four stroke, two cylinder horizontally opposed Boxer, two camshafts and four radially aligned valves per cylinder, central counter balancer shaft., displacement 1170 cc / 71.4 cub in , produces power 81 kW / 109 hp @ 7000 rpm and 115 Nm / 81 lb-ft @ 6500 rpm. BMW R 12 nineT wet weight is 220 kg / 485 lbs. BMW R 12 nineT has 7 photos.

Technical specifications

+ Add to 'Compare list'

Model:	R 12 nineT
Years:	2024
Engine:	Four stroke, two cylinder horizontally opposed Boxer, two camshafts and four radially aligned valves per cylinder, central counter balancer shaft.
Capacity:	1170 cc / 71.4 cub in
Bore x Stroke:	101 x 73 mm
Compression Ratio:	12:1
Cooling System:	Air/oil cooled
Lubrication:	Wet sump
Induction:	Electronic intake pipe injection / digital engine management system: BMS-O with throttle-by-wire
Emission:	Controlled 3-way catalytic converter, exhaust emission standards EU-59
Fuel:	Unleaded super (premium), octane number 95-98 (RON) (rated output at 98 RON)
Starting:	Electric
Max Power:	81 kW / 109 hp @ 7000 rpm
Max Torque:	115 Nm / 81 lb-ft @ 6500 rpm
Clutch:	Single dry plate clutch, hydraulically operated
Transmission:	6-speed, claw-shifted transmission with separate transmission housing
Primary Ratio:	1.737
Gear Ratio:	1st = 2.375, 2nd = 1.696, 3rd = 1.296, 4th = 1.065, 5th = 0.939, 6th = 0.848
Final Drive:	Shaft
Transmission Ratio:	2.910
Frame:	Four-part frame concept with front frame and three-part rear frame, load-bearing engine-gearbox unit, rear-seat frame removeable for one-up riding
Front Suspension:	46 mm upside-down telescopic forks
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring strut, spring preload fully adjustable by hook wrench, adjustable rebound-stage damping
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	Twin disc brake, floating brake discs, diameter 310 mm, 4-piston Monobloc radial brake caliper
Rear Brakes:	Single 265 mm disc, 2 piston floating caliper
ABS System:	BMW Motorrad ABS Pro
Wheels:	Aluminium cast wheels
Front Rim:	3.50 x 17
Rear Rim:	5.50 x 17
Front Tyre:	120/70 - ZR17
Rear Tyre:	180/55 - ZR17
Rake:	27.7 ?
Trail:	112 mm / 4.4 in
Dimensions:	Length 2131 mm / 83.9 in Width 871 mm / 34.3 in
Wheelbase:	1511 mm / 59.5 in
Seat Height:	795 mm / 31.3 in
Wet Weight:	220 kg / 485 lbs
Fuel Capacity:	15.9 Litres / 4.2 US gal
