BMW K 1200LT (2003-05) technical specifications

BMW K 1200LT technical specifications

BMW K 1200LT is produced in 2003-05. Engine is Four stroke, horizontal in line four cylinder, DOHC, 4 valves per cylinder, displacement 1172 cc / 71.5 cu in , produces power 72 kW / 98 hp @ 6750rpm and 115 Nm / 11.7 kgf-m / 84 ft-lb @ 4750 rpm. BMW K 1200LT top speed is 198 km/h / 123 mph. BMW K 1200LT weighs 345 kg / 761 lbs. BMW K 1200LT has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: K 1200LT
Years: 2003-05
Engine: Four stroke, horizontal in line four cylinder, DOHC, 4 valves per cylinder
Capacity: 1172 cc / 71.5 cu in
Bore x Stroke: 75 x 70.5 mm
Compression Ratio: 10.8:1
Cooling System: Liquid cooled
Induction: Electronic intake pipe injection
Ingnition: MA 2.4 Bosch Motronic
Starting: Electric
Max Power: 72 kW / 98 hp @ 6750rpm
Max Torque: 115 Nm / 11.7 kgf-m / 84 ft-lb @ 4750 rpm
Transmission: 5 Speed
Final Drive: Shaft
Gear Ratio: 1st 2.050 / 2nd 1.600 / 3rd 1.270 / 4th 0.960 / 5th 0.700:1
Frame: Bridging frame consisting of die cast aluminium, engine de-coupled from vibration through bearings
Front Suspension: Motorrad Telelever, stanchion diameter ∅35 mm, central strut
Rear Suspension: Die cast Aluminum single sided swinging arm with Paralever, central strut, spring preload adjustable to continuously variable levels by mean of hydraulic hand wheel
Front Brakes: 2 x ∅320mm disc, 4 piston calipers, ABS
Rear Brakes: Single ∅285mm disc, 2 piston caliper, ABS
Front Tyre: 120/70 ZR17
Rear Tyre: 160/70 ZR17
Seat Height: 770 mm / 30.3 in
Dry Weight: 345 kg / 761 lbs
Wet Weight: 378 kg / 833 lbs
Fuel Capacity: 22 L / 5.8 US gal
Consumption Average: 6.0 L/100 km / 16.8 km/l / 39.5 US mpg
Standing ¼ Mile: 13.3 sec
Top Speed: 198 km/h / 123 mph
