BMW F 750GS (2022) technical specifications

BMW F 750GS technical specifications

BMW F 750GS is produced in 2022. Engine is Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder, displacement 853 cc / 52 ci-in , produces power 77 hp / 57.4 kW @ 7500rpm and 83 Nm / 61.2 lb-ft @ 6000rpm. BMW F 750GS wet weight is 227 kg / 500 lbs. BMW F 750GS has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: F 750GS
Years: 2022
Engine: Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Capacity: 853 cc / 52 ci-in
Bore x Stroke: 84 x 77mm
Compression Ratio: 12.7:1
Cooling: Liquid cooled
Lubrication: Dry sump
Induction: Electronic intake injection
Emission: Closed-loop 3-way catalytic converter, emission standard EU-5
Ignition: Knock control and oxygen sensors
Starting: Electric
Max Power: 77 hp / 57.4 kW @ 7500rpm
Max Torque: 83 Nm / 61.2 lb-ft @ 6000rpm
Clutch: Multiplate wet clutch (anti-hopping), mechanically controlled
Transmission: Constant-Mesh 6 speed gearbox integrated in crankcase
Final Drive: Endless O-ring chain with shock damping in rear wheel hub
Frame: Steel bridge frame in monocoque design, load-bearing engine
Front Suspension: 41mm telescopic forks
Front Wheel Travel: 170 mm / 6.7 in - OE suspension lowing kit 150mm / 5.9 in
Rear Suspension: Cast aluminium dual swing arm, central spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable
Rear Wheel Travel: 170 mm / 6.7 in - OE suspension lowing kit 150mm / 5.9 in
Front Brakes: 2 x 305mm discs, 2 piston floating calipers
Rear Brakes: Single 265mm disc,1 piston floating caliper
ABS: BMW Motorrad ABS
Front Wheel: Cast aluminum 19 x 2.5 in
Rear Wheel: Cast aluminum 17 x 4.25 in
Front Tyre: 110/80 R19
Rear Tyre: 150/70 R17
Steering Head Angle: 63°
Castor: 104.5 mm / 4.1 in
Dimensions: Length: 2255 mm / 88.8 in Width: 922 mm / 36.3 in (incl. mirrors) Height: 1225 mm / 48.2 in (ecxl. mirrors)
Wheelbase: 1559 mm / 61.4 in
Seat Height: 815 mm / 32 in - OE suspension lowering kit: 770 mm / 30.3 in - OE low seat: 790 mm / 31.1 in - OE comfort seat: 830 mm / 32.6 in
Wet Weight: 227 kg / 500 lbs
Fuel Capacity: 15 Litres / 4.0 US gal
