2018 BMW F 750GS technical specifications

Technical specifications

Model: F 750GS
Years: 2018
Engine: Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Capacity: 853 cc / 52 ci-in
Bore x Stroke: 84 x 77mm
Compression Ratio: 12.7:1
Cooling: Liquid cooled
Induction: Electronic intake injection
Ignition: Knock control and oxygen sensors.
Starting: Electric
Max Power: 77 hp / 57.4 kW @ 7500rpm
Max Torque: 83 Nm / 61.2 lb-ft @ 6000rpm
Clutch: Multiplate wet clutch (anti-hopping), mechanically controlled
Transmission: Constant-Mesh 6 speed
Final Drive: O-ring chain
Frame: Steel bridge frame in monocoque design, load-bearing engine
Front Suspension: 41mm telescopic forks
Front Wheel Travel: 151 mm / 5.1 in
Rear Suspension: Aluminum double-sided swing arm, directly mounted, preload and rebound damping adjustable (Dynamic ESA)
Rear Wheel Travel: 177 mm / 7.0 in
Front Brakes: 2 x 305mm discs, 2 piston calipers, ABS
Rear Brakes: Single 265mm disc,1 piston caliper, ABS
Front Wheel: Cast aluminum 19 x 2.5 in
Rear Wheel: Cast aluminum 17 x 4.25 in
Front Tyre: 110/80-19
Rear Tyre: 150/70-17
Dimensions: Length: 2255 mm / 88.8 in Width: 922 mm / 36.3 in (incl. mirrors)
Wheelbase: 1559 mm / 61.4 in
Seat Height: 770-830 mm / 30.3-32.7 in
Wet Weight: 224 kg / 494 lbs
Fuel Capacity: 15 Litres / 4.0 US gal
