Technical specifications
|
| Model: |
F 750GS |
| Years: |
2018 |
|
Engine:
|
Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
|
|
Capacity:
|
853 cc / 52 ci-in
|
|
Bore x Stroke:
|
84 x 77mm
|
|
Compression Ratio:
|
12.7:1
|
|
Cooling:
|
Liquid cooled
|
|
Induction:
|
Electronic intake injection
|
|
Ignition:
|
Knock control and oxygen sensors.
|
|
Starting:
|
Electric
|
|
Max Power:
|
77 hp / 57.4 kW @ 7500rpm
|
|
Max Torque:
|
83 Nm / 61.2 lb-ft @ 6000rpm
|
|
Clutch:
|
Multiplate wet clutch (anti-hopping), mechanically controlled
|
|
Transmission:
|
Constant-Mesh 6 speed
|
|
Final Drive:
|
O-ring chain
|
|
Frame:
|
Steel bridge frame in monocoque design, load-bearing engine
|
|
Front Suspension:
|
41mm telescopic forks
|
|
Front Wheel Travel:
|
151 mm / 5.1 in
|
|
Rear Suspension:
|
Aluminum double-sided swing arm, directly mounted, preload and rebound damping adjustable (Dynamic ESA)
|
|
Rear Wheel Travel:
|
177 mm / 7.0 in
|
|
Front Brakes:
|
2 x 305mm discs, 2 piston calipers, ABS
|
|
Rear Brakes:
|
Single 265mm disc,1 piston caliper, ABS
|
|
Front Wheel:
|
Cast aluminum 19 x 2.5 in
|
|
Rear Wheel:
|
Cast aluminum 17 x 4.25 in
|
|
Front Tyre:
|
110/80-19
|
|
Rear Tyre:
|
150/70-17
|
|
Dimensions:
|
Length: 2255 mm / 88.8 in Width: 922 mm / 36.3 in (incl. mirrors)
|
|
Wheelbase:
|
1559 mm / 61.4 in
|
|
Seat Height:
|
770-830 mm / 30.3-32.7 in
|
|
Wet Weight:
|
224 kg / 494 lbs
|
|
Fuel Capacity:
|
15 Litres / 4.0 US gal
|
