Aprilia Atlantic 400 Sprint (2007-09) technical specifications

Aprilia Atlantic 400 Sprint technical specifications

Aprilia Atlantic 400 Sprint is produced in 2007-09. Engine is Four stroke, single cylinder, SOHC, 4 valves, displacement 399 cc / 24.3 cu in , produces power 25.3 kW / 34 hp @ 7500 rpm and 37 Nm / 3.8 kgf-m / 27.3 lb-ft @ 5500 rpm. Aprilia Atlantic 400 Sprint weighs 199 kg / 439 lbs. Aprilia Atlantic 400 Sprint has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: Atlantic 400 Sprint
Years: 2007-09
Engine: Four stroke, single cylinder, SOHC, 4 valves
Capacity: 399 cc / 24.3 cu in
Bore x Stroke: 86 x 69 mm
Compression Ratio: 10.5:1
Cooling System: Liquid cooled
Lubrication: Wet sump, forced with mechanical oil pump
Induction: Electronic fuel injection.
Ignition: Electronic CDI with automatic advance
Starting: Electric
Alternator: 12V, 380W
Max Power: 25.3 kW / 34 hp @ 7500 rpm
Max Torque: 37 Nm / 3.8 kgf-m / 27.3 lb-ft @ 5500 rpm
Transmission: CVT
Final Drive: V-belt
Frame: High-strength tubular steel frame with closed double cradle.
Front Suspension: Hydraulic fork, Ø35 mm
Front Wheel Travel: 105 mm / 4.1 in
Rear Suspension: Engine acting as swingarm. Two gas filled shock absorbers with 5 position spring preload adjustment.
Rear Wheel Travel: 90 mm / 3.5 in
Front Brakes: Single Ø260 mm disc
Rear Brakes: Single Ø190 mm disc
Wheels: Light alloy, 5 spoke
Front Wheel: 3.00 x 14
Rear Wheel: 3.75 x 14
Front Tyre: 120/70 -14
Rear Tyre: 140/60 -14
Dimensions: Length: 2200 mm / 86.6 in Width: 815 mm / 32.1 in Height: 1370 mm / 53.9 in
Wheelbase: 1550 mm / 61.0 in
Seat height: 780 mm / 30.7 in
Dry Weight: 199 kg / 439 lbs
Fuel Capacity: 15 Litres / 4.0 US gal
Fuel Reserve: 2 Litres / 0.5 US gal
