AJS Model 18 500 (S, CS, Statesman) (1945-66) technical specifications
AJS Model 18 500 (S, CS, Statesman) is produced in 1945-66. Engine is Single cylinder, 2 valve per cylinder, pushrod OHV, displacement 498 c / 30.4 cu in , produces power 20.9 kW / 28 hp @ 5600 rpm. AJS Model 18 500 (S, CS, Statesman) weighs Standard rigid frame: 15660 kg / 353 lbs Spring frame: 175 kg / 386 lbs Competition rigid frame: 137 kg / 303 lbs. AJS Model 18 500 (S, CS, Statesman) has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Model 18 500 (S, CS, Statesman) |
| Years: | 1945-66 |
| Engine: | Single cylinder, 2 valve per cylinder, pushrod OHV |
| Capacity: | 498 c / 30.4 cu in |
| Bore x Stroke: | 82.5 x 93 mm |
| Compression ratio: | 6.90:1 (with compression plate) 7.24:1 (with no compression plate) |
| Cooling system: | Air cooled |
| Lubrication: | Dry sump |
| Oil Capacity: | 2.3 L / 4.8 US pt |
| Induction: | Carburetor, type 89B/IAK |
| Ignition: | Lucas magneto |
| Starting: | Kick |
| Max Power: | 20.9 kW / 28 hp @ 5600 rpm |
| Transmission: | 4 Speed, Burman gearbox |
| Drive: | Chain |
| Front Suspension: | Hydraulic telescopic fork |
| Rear Suspension: | Swinging arm, dual shocks |
| Front Brakes: | Drum |
| Rear Brakes: | Drum |
| Wheels: | Steel, wire spokes |
| Front Tyre: | 3.25 -19 |
| Rear Tyre: | 34.25 -19 |
| Wheelbase: | 1400 mm / 55 in |
| Seat Height: | 760 mm / 30 in |
| Dry-Weight: | Standard rigid frame: 15660 kg / 353 lbs Spring frame: 175 kg / 386 lbs Competition rigid frame: 137 kg / 303 lbs |
| Fuel Capacity: | Rigid, Spring frame: 13 L / 4.23.4 US gal Competition: 10.2 L / 2.7 US gal |
