AJS EOS 125 Mk2 (2012-14) technical specifications

AJS EOS 125 Mk2 technical specifications

AJS EOS 125 Mk2 is produced in 2012-14. Engine is Twin cylinder, 4-stroke, displacement 124 cc / 7.6 cub in , produces power 8 kW / 11 hp @ 9500 rpm. AJS EOS 125 Mk2 weighs 180 kg / 397 lbs. AJS EOS 125 Mk2 has 2 photos.

Technical specifications

+ Add to 'Compare list'
Model: EOS 125 Mk2
Years: 2012-14
Engine: Twin cylinder, 4-stroke
Capacity: 124 cc / 7.6 cub in
Bore x Stroke: 44 x 40 mm
Cooling System: Liquid cooled
Exhaust: 2-into-2, chrome
Ignition: Coil, CDI
Battery: 12V
Starting: Electric
Max Power: 8 kW / 11 hp @ 9500 rpm
Clutch: Wet, multi-plate
Transmission: 5-Speed
Final Drive: Chain
Front Suspension: Telescopic forks, USD
Rear Suspension: Twin shock
Front Brakes: Twin disc
Rear Brakes: Single disc
Wheels: Multi spoke, alloy
Front Tyre: 80/90-21
Rear Tyre: 160/80-16
Wheelbase: 1860 mm / 73 in.
Seat Height: 640 mm / 25 in
Dry Weight: 180 kg / 397 lbs
GVWR: 330 kg / 728 lbs
Fuel Capacity: 14 L / 3.7 US gal
Colours: Black with chrome panels
