Adler M 200 (1952) technical specifications
Adler M 200 is produced in 1952. Engine is Air cooled, two stroke, parallel twin cylinder, displacement 195 , produces power 11,4 hp @ 5450 rpm. Adler M 200 weighs 130 kg. Adler M 200 has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | M 200 |
| Years: | 1952 |
| Engine: | Air cooled, two stroke, parallel twin cylinder |
| Capacity: | 195 |
| Bore x Stroke: | 48 x 54 mm |
| Compression Ratio: | 5.75:1 |
| Induction: | Carburetor |
| Ignition / Starting: | 6 volt / kick |
| Max Power: | 11,4 hp @ 5450 rpm |
| Transmission / Drive: | 4 Speed / chain |
| Frame: | Semi double cradle |
| Front Suspension: | Plunger type shocks |
| Rear Suspension: | Dual chocks |
| Front Brakes: | 150mm Drum |
| Rear Brakes: | 150mm Drum |
| Front Tyre: | 3,.5 -16 |
| Rear Tyre: | 3,.5 -16 |
| Dry Weight: | 130 kg |
| Fuel Capacity: | 12 Litres |
