Adler M 100 (1949-56) technical specifications
Adler M 100 is produced in 1949-56. Engine is 1 cylinder, 2 stroke, displacement 98 cc / 6 cub in. , produces power 3 kW / 4.1 hp. Adler M 100 top speed is 70 km/h / 43.5 mph. Adler M 100 weighs 55 kg / 121 lbs. Adler M 100 has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | M 100 |
| Years: | 1949-56 |
| Production: | 35 000 units |
| Engine: | 1 cylinder, 2 stroke |
| Capacity: | 98 cc / 6 cub in. |
| Bore x Stroke: | 50 x 50 mm |
| Cooling: | Air cooled |
| Lubrication: | Petrol oil mix 25:1 |
| Clutch: | Multi plate, wet, cable operated |
| Starting: | Kick start |
| Ignition: | Magneto |
| Carburetor: | Single built into block |
| Exhaust System: | Single, steel and crome |
| Max Power: | 3 kW / 4.1 hp |
| Compression Ratio: | 1: 5.75 |
| Transmission: | 3 Speed gearbox |
| Final Drive: | Chain |
| Frame: | Double cradle steel frame |
| Front suspension: | Leading link |
| Rear suspension: | Twon shock, plunger |
| Brake: | Drum, 125 mm |
| Dimensions: | Length 1900 mm / 74.8 in. Width 650 mm / 25.6 in. Height 865 mm / 34.1 in. |
| Dry Weight: | 55 kg / 121 lbs |
| Fuel Capacity: | 7 L / 1.8 US gal |
| Top Speed: | 70 km/h / 43.5 mph |
| Colours: | Black with gold striping / Red with gold striping |
