Adler Favorit (1957-60) technical specifications
Adler Favorit is produced in 1957-60. Engine is 2 cylinder, 2 stroke, inline, displacement 247 cc / 15.1 cub in. , produces power 11.8 kW / 16 hp @ 5600rpm. Adler Favorit top speed is 116 km/h / 72 mph. Adler Favorit weighs 165 kg / 364 lbs. Adler Favorit has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Favorit |
| Years: | 1957-60 |
| Engine: | 2 cylinder, 2 stroke, inline |
| Capacity: | 247 cc / 15.1 cub in. |
| Bore x Stroke: | 54 x 54 mm |
| Cooling: | Air cooled |
| Lubrication: | Petrol oil mix 25:1 |
| Clutch: | Multi plate, wet, cable operated |
| Starting: | Kick start |
| Battery: | 6V, 6Ah |
| Ignition: | Magneto |
| Carburetor: | Single Bing carburetor |
| Exhaust System: | Twin, steel, chrome |
| Max Power: | 11.8 kW / 16 hp @ 5600rpm |
| Compression Ratio: | 1: 6.6 |
| Transmission: | 4 Speed gearbox housed in engine block, foot gearchange |
| Final Drive: | Chain, fully enclosed |
| Frame: | Double cradle steel frame |
| Front suspension: | Cartridge |
| Rear suspension: | Plunger shock absorbers, adjustable for load and road conditions |
| Front Tyres: | 3.25 x 16 in. |
| Rear Tyres: | 3.50 x 16 in. |
| Brakes (front and back): | Drum, 180 mm diameter |
| Dimensions: | Length 1975 mm / 77.8 in. Width 620 mm / 24.4 in. Height 950 mm / 37.4 in. |
| Wheelbase: | 1257 mm / 49.5 in. |
| Dry Weight: | 165 kg / 364 lbs |
| Fuel Capacity: | 15 L / 4 US gal |
| Reserve: | 3.8 L / 1 US gal |
| Top Speed: | 116 km/h / 72 mph |
| Colours: | Black, Blue-Green |
